Looking for a budget-friendly, rock-solid foundation for your custom rear suspension? Look no further. Our fabricated steel Ford 9 inch axle housing kit including two axles for maximum durability.

Fabricated with the Builder in Mind

This housing is pumpkin-centered with uniform-length axle tubes, side-to-side. So mounting suspension brackets, especially on triangulated 3-link and 4-link systems, is much easier. Note that the pumpkin-centered design will offset the pinion yoke about 1" to the passenger side.

Axle tubes are 3” O.D. with a 3/16” wall thickness. Heavy-wall tubes, along with a larger center section, significantly reduce distortion during welding of rear-link brackets or spring pads. Billet steel “New Big Ford” (Torino) style bearing ends are fixture-welded (3.150” O.D. bearing, with 2.50” axle flange offset).

Total wheel-to-wheel mounting surface width is 56" (from hub-to-hub). The pumpkin is centered in the housing, which puts the pinion 1" offset from center, requiring different length axle shafts. This 56" rear end housing kit includes two 31 Spline 29.5" cut-to-fit axles The housing includes (8) T-bolts for the axle bearing retainer plates and (10) studs for the third member.

Steel Axles

Our axle housings deserve strong axles to drive your street machine. Two axles made of alloy steel have the strength to handle the horsepower. Axles are 31-spline, includes axle bearings, axle seals, and bearing retainers. Flanges are drilled for both 5 on 4-1/2" Ford/Mopar, 5 on 4-3/4" GM, 5 on 5" GM Truck wheel bolt patterns.

• New fabricated steel center section
• 3" O.D. axle tubes with 3/16" wall thickness
• Billet steel "New Big Ford" (Torino) style bearing ends
• Forged Steel axle, drilled for 5 on 4-1/2" Ford/Mopar, 5 on 4-3/4" GM car, and 5 on 5" GM Truck Bolt patterns using 0.685" knurl diameter
• Street application 1/2" thread wheel studs sold separately
• Accepts brake kits for 2.50" axle shaft flange offset (from housing flange)
• Housing measures 51" from flange-to-flange
• Assembled rearend measures 56" from hub-to-hub (axle flange face-to-face)
• Includes two 31 spline 29.5" Axles Cut-to-fit with bearings
• Centered pumpkin w/ 1" offset pinion yoke for easy suspension mock-up
• Requires different length axle shafts, left/right
• Includes vent on driver side axle tube
• Includes studs for 3rd member and 3/8” T-bolts for bearing retainer plates
• 3rd member sold separately

For more information on determining the proper axle length and the Ford 9 Inch, be sure to check out our tech articles; Measure and ID Axles and Housings and  Specs
