Leister VARIANT T1 TAPE 25mm / 50mm 230V 3680W or 400V 5700W
DETAILS Securing the truck cargo
The VARIANT T1 tape welding machine is perfect for welding reinforcement and anti-vandalism tapes on truck tarpaulins or billboards. Thanks to the "e-drive" operating concept, setting the relevant welding parameters couldn't be easier. The tape delivery system and the newly developed guide rollers direct the tape under the pressure roller, keeping it taught right up to the last bit.
Optimized for truck cargo, this model helps reinforce truck tarpaulins, rendering them tear/theft-proof (anti-vandalism tape).
Technical Data
Frequency: 50/60 Hz
Speed: 1.5 - 18 m/min / 4.92 - 59.05 ft/min
Temperature: 100 - 620 °C / 212 - 1148 ℉
Air Volume Adjustable: Yes
LQS: No
Brushless Blower Motor: Yes
Length: 700 mm / 27.55 in
Width: 400 mm / 15.74 in
Height: 230 mm / 9.05 in
Weight: 28 kg / 61.72 lb
Power Cable Length: 1.2 m / 3.93 ft
Approvals: CE; UKCA
Protection Class: I
Country Of Origin: Switzerland
Features:
- Quick and precise
- e-Drive operating unit
- Easy to use
- Taut tape guidance
- Reinforcement tapes and anti-vandalism tapes
HIGHLIGHTS Welding reinforcement tapes
OPERATION VIA E-DRIVE
Parameters are monitored constantly
The “e-Drive” digital display offers continuous monitoring and control of speed, temperature and air volume. Material-specific parameters are saved.
PERFECT GUIDANCE
Taut tape guidance
The tape guiding rollers makes it easy to position the tape and keep tension on it.
VERSATILE
Conversion kit for anti-vandalism tape
The welding machine can easily be converted from 50 mm to 25 mm (anti-vandalism tape) or vice versa.
APPLICATIONS Virtually unlimited
Advertising banner welding
Protective cover welding
Textile roofing and facade welding
Tent tarpaulin welding
Awning and wind blocker welding
Flexible tank welding
Truck tarpaulin welding
The VARIANT T1 tape welding machine is perfect for welding reinforcement and anti-vandalism tapes on truck tarpaulins or billboards. Thanks to the "e-drive" operating concept, setting the relevant welding parameters couldn't be easier. The tape delivery system and the newly developed guide rollers direct the tape under the pressure roller, keeping it taught right up to the last bit.
Optimized for truck cargo, this model helps reinforce truck tarpaulins, rendering them tear/theft-proof (anti-vandalism tape).
Technical Data
|
Article |
Voltage |
Power |
Welding Nozzle / Seam Width |
Plug |
|
148.963 |
230 V |
3680 W |
25 mm / 0.98 in |
EU, 3 poles, 16A |
|
148.964 |
230 V |
3680 W |
50 mm / 1.96 in |
EU, 3 poles, 16A |
|
148.965 |
400 V |
5700 W |
25 mm / 0.98 in |
CEE red, 5 poles, 16A |
|
148.966 |
400 V |
5700 W |
50 mm / 1.96 in |
CEE red, 5 poles, 16A |
Frequency: 50/60 Hz
Speed: 1.5 - 18 m/min / 4.92 - 59.05 ft/min
Temperature: 100 - 620 °C / 212 - 1148 ℉
Air Volume Adjustable: Yes
LQS: No
Brushless Blower Motor: Yes
Length: 700 mm / 27.55 in
Width: 400 mm / 15.74 in
Height: 230 mm / 9.05 in
Weight: 28 kg / 61.72 lb
Power Cable Length: 1.2 m / 3.93 ft
Approvals: CE; UKCA
Protection Class: I
Country Of Origin: Switzerland
Features:
- Quick and precise
- e-Drive operating unit
- Easy to use
- Taut tape guidance
- Reinforcement tapes and anti-vandalism tapes
HIGHLIGHTS Welding reinforcement tapes
OPERATION VIA E-DRIVE
Parameters are monitored constantly
The “e-Drive” digital display offers continuous monitoring and control of speed, temperature and air volume. Material-specific parameters are saved.
PERFECT GUIDANCE
Taut tape guidance
The tape guiding rollers makes it easy to position the tape and keep tension on it.
VERSATILE
Conversion kit for anti-vandalism tape
The welding machine can easily be converted from 50 mm to 25 mm (anti-vandalism tape) or vice versa.
APPLICATIONS Virtually unlimited
Advertising banner welding
Protective cover welding
Textile roofing and facade welding
Tent tarpaulin welding
Awning and wind blocker welding
Flexible tank welding
Truck tarpaulin welding
