BEI Ideacod CHM5 13-bit BiSS Absolute Linear Encoder, 10 mm Range, 11–30 V DC

The BEI Ideacod CHM5 13-bit BiSS absolute linear encoder delivers precise position feedback over a 10 mm measuring range. Featuring an 8192-step resolution, BiSS digital interface, and wide 11–30 V DC supply, this encoder is ideal for CNC machines, robotics, and automated systems demanding high accuracy and reliability.

Features:

• Brand: BEI Ideacod
• Model: CHM5
• Resolution: 13-bit (8192 positions)
• Interface: BiSS digital protocol
• Measuring Range: 10 mm
• Supply Voltage: 11–30 V DC
• Output Code: Natural binary
• Material: Hardened stainless steel sensor rod
• Housing: Rugged aluminum, IP54-rated

Technical Specifications:

• Supply Current: ≤ 50 mA
• Operating Temperature: -10 °C to +70 °C
• Shock Resistance: 100 m/s², 11 ms
• Vibration Resistance: 100 m/s², 10–2000 Hz
• Connector: 8-pin M12
• Data Retention: Non-volatile memory

Key Benefits:

• High Accuracy: Low quantization error for precise control.
• Robust Design: Resistant to dust, vibration, and shock.
• Wide Voltage Range: Flexibility across industrial power systems.
• Easy Integration: Standard BiSS interface for seamless setup.

Important Notes:

• Verify correct wiring and 11–30 V DC supply before installation.
• Calibration recommended upon first use for optimal accuracy.
• VAT invoices available upon request.
• 30-day returns accepted; buyer pays return shipping.
