The 4 kg Weldy miniwelder roof2 is extremely light and easy to operate. It can be used on all pitched roofs and is ideal for all PVC and TPO membranes between 0.3 and 1 mm thickness. Welding temperatures between 60 and 480°C are continuously variable. An additional advantage is that the membranes do not flap when they are welded. Appropri   ate for the material, chrome steel, aluminum, or copper hot-wedge ensures safe contact welding. No expensive, toxic solvent-welding agents required

Specification:

Voltage: 230V

Frequency: 50/60 Hz

Power: 800W

Temperature: 60 - 480 °C / 140.0 - 896.0 °F

Speed: 0.4 - 7.5 m/min / 1.31 - 24.6 ft/min

Welding technology: Hot wedge

Hot wedge length: 50 mm / 1.96 in

Hot wedge width: 40 mm / 1.57 in

Hot wedge material: Hard ematalised aluminum

Max. overlap: 80 mm / 3.14 in

Roll material: Silicone roller 50 shore A

LQS: No

Display：No

Size (L × W × H): 228 x 228 x 170 mm / 8.97 x 8.97 x 6.69 in

Weight: 4.0 kg / 8.81 lb

Welding material: PVC; TPO

Weldable material thichnesses: 0.3 - 1.0 mm / 11.81 - 39.37 mil

Power cable length: 3.0 m / 9.84 ft

Plug: EU, 3 poles, 16A

Protection class: I

Approvals: CE

Highlights:

1. Lightweight and easy to operate: 4 kg (8.8 lbs) light

2. Suitable for all pitched roofs, even under exceptional loads

3. Ideal for pre-assembling

4. For thin PVC and TPO sub-roof membranes with thicknesses between 0.3 and 1 mm

5. Can be used in high and low outdoor temperatures

6. Reliable contact welding thanks to chromium steel welding wedge

7. Ergonomic guide bar

8. Lightweight and user-friendly at just 4 kg(8.8 lbs)

9. No expensive, toxic solvent welding agent required

10. Easy handling

11. Up to five times faster than manual welding

12. Good quality and good value

Application:
