    Your Checklist



    • Direct replacement

    • Ideal solution

    • Upgraded construction

    • Trustworthy quality





    Details Description



    • Accurate control of throttle opening



    • Improved engine emission performance



    • Achieve higher vehicle driving reliability



    • Achieve the best of the full range of engines





    The mechanic will replace the throttle body on your car if



    • It can’t be cleaned properly.

    • The throttle flap, throttle shaft, or the mechanical linkages to the throttle cable are damaged.

    • The electronic throttle actuator is faulty.

    • There is a damaged throttle body or TP sensor electrical connector.



    Additionally, it’d be a good idea to get your cars throttle and fuel delivery system inspected for



    1. A faulty throttle position sensor

    2. Gas pedal sensor problems

    3. Intake manifold pressure sensor issues

    4. A clogged air filter

    5. A bad Mass Airflow sensor (MAF sensor)

    6. A failing fuel pump

    7. A malfunctioning fuel injector

    8. A defective fuel pressure regulator
      ​
    9. These parts can cause problems similar to bad throttle body symptoms.

    ​



    Throttle Body Replacement



    1. Refer to the service manual for identification and location of the throttle body.



    2. Remove the air intake duct from the throttle body once it is located.



    3. Check the throttle body as well as the assembly and ports. If there is wearing in the assembly it may also require replacement.



    4. Pull out the cables from the throttle body.



    5. Remove the hoses such as air or vacuum hoses from the throttle body.



    6. Disconnect the throttle position sensor.



    7. Remove the screws that are holding the throttle body in the assembly.



    8. Remove the throttle body carefully after disconnecting everything.



    9. Properly clean the assembly and port to remove any carbon build up.



    10. Compare the old throttle body with the new one.



    11. Install the throttle body in the port.



    12. Fasten the bolts and screws to hold it in place.



    13. Connect all the things that you previously removed.



    14. After connecting everything start your engine and test for the new throttle body.



    15. Perform the following check as a final test.

    Start the engine and take the car for a test drive.

    On your return, let the engine idle for about two minutes and listen for problems in the idle, ensuring that it is smooth.

    If it is not, then there may be additional problems throughout your engine.








    Item Specifics
    Brand topoint-autoparts
    Manufacturer Part Number TO10474101T
    Fitment Type Direct Replacement
    Bore Diameter 57mm
    Housing Length (in) 5-1/16
    Housing Width (in) 4-7/8
    Main Port Inside Diameter(in) 2-5/16
    Air Intake Port Maximum Diameter (in) 2-11/16
    Mount Hole Quantity 4
    Connector Quantity 1
    Fuel System Type FI
    Throttle Plate Diameter (in) 2-1/4
    Terminal QTY 6
    Gaskets Included No
    Material Aluminum
    Features Electrical
    Items Included One Complete Throttle Body w/Sensor
    Packaging Type Box
    Modified Item No
    Custom Bundle No
    Placement on Vehicle Front
    Non-Domestic Product Yes
    Mounting Hardware Included No
    Manufacturer Warranty 1 Year
    Interchange Part Number 67-4003, S20070
    Superseded Part Number A2C59511705, TB1024, 06F133062A, 06F133062Q
    Type Throttle Body
    Weight 3 LB
    Connector Color Black
    OE/OEM Part Number 06F133062E, 06F133062G, 06F133062J, 06F133062T
    Color White
