Riser PCIe x4 3.0 PCI-E 4x To M.2 NGFF NVMe 2280 Riser Card Extension Cord
Riser PCIe x4 3.0 PCI-E 4x To M.2 NGFF NVMe M Key 2280 Riser Card Gen3.0 Cable M2 Key-M PCI-Express Extension cord 32G/bps
Note:
1.Due to production batch issues, the appearance may change somewhat, but does not affect its usage.
2.Length is customizable,cable prices of different lengths are not the same,pls contact us if you need!
Brand: ADT
Product model: R42 series of goods
Product Name: PCI-E Adapter Board Extension Cable
Wire length: 10~80cm, support batch order customization
Bandwidth speed: PCIe 3.0x4 gen3; 32G/bps
Applicable card: high-speed network card, capture card, NVMe SSD hard disk card, USB adapter card, support PCI-E x4 interface.
Note: This product does not support notebook external.
R4x series product model description:
Wire length description:
The
length of the wire refers to the part of the visible wire. It does not
include the PCB and the connector. Refer to the figure 8cm in the blue
figure below.
Product advantage:
1.
Wire advantages: using the German patent imported wire, using the Lotes
connectors which imported from Taiwan, high frequency support PCIe
3.0x4 32G/bps stable transfer.
2.Differential
signal without hole design, there is no problem of signal attenuation
interference in a parasitic capacitance and parasitic inductance, there
will be no more CAF micro short circuit, cable is durability.
3.PCB
use high frequency low resistance of materials with high quality, PCB
using high TG board, copper thickness thicken to 1oz, gold finger
plating enough gold, Good conductive performance, can reduce oxidize
higher impedance caused by the crash blue screen.
Product Image：
