5 arcmin 115 high Precision Helical planetary reducer gearbox 10:1 for Delta 100mm frame AC servo motor input shaft 22mm
the matched Delta servo motor models as following:
ECMA-C21010RS,ECMA-C11010RS,ECMA-C21020RS and ECMA-C11020RS

PLEASE READ THE FOLLOWING NOTICE BEFORE ORDER：

1^st:Reduction Ratio .you ordered 10:1 ratio

The reduction ratio of the planetary reducer including 1 stage reducer ratio: 3:1,4:1,5:1,7:1,10:1 .

If you need other ratios,PLEASE inquiry before order to confirm lead time .

2^nd:Input Size

We will ship the planetary reducer as the standard dimension as follows:

If any question on the dimension of the planetary reducer, please write me the dimension drawing of your motor. We offer customize service for your motor and can help you choose the suitable planetary reducer for your motor.

 the Delta servo motor size as following:

3^rd:Parameters

We can offer higher precision version such as backlash 3 arc-min( P1 grade), If you have inquiry to customize the precision ,input and output dimensions, reduction ratio please write me

Here is the parameters of the planetary reducer:
