Buying from TF Pumps You’re buying from a UK business investing in more responsible operations, including 80 on-site solar panels at our Derby HQ.Jabsco Q401J-115S-3A 1/2" Par Max HD 4 Pressure-Controlled Pump 15 LPM | 12 Volt
Model: ParMax | Q401J-115S-3A
The Jabsco Par-Max HD4 Heavy-Duty Marine Freshwater Delivery Pump (Model Q401J-115S-3A 1/2) is a robust, 12-volt diaphragm pump engineered for demanding marine water systems. Delivering up to 4 GPM (15.1 L/min), this pump offers seamless, on-demand performance via its integrated, sealed pressure switch. With a heavy-duty build featuring a fiber-reinforced polypropylene upper housing and cast aluminum lower housing, the pump ensures exceptional durability. It is self-priming, can run dry without damage, and includes a built-in bypass to reduce cycling for smoother flow—all wrapped in a quiet, efficient design.
Applications
- Marine freshwater systems — ideal for galley faucets, showers, and washdown stations
- Boats and caravans — provides reliable freshwater delivery for multi-outlet systems
- General-purpose water transfer — well-suited for applications needing pressure and flow control in compact spaces, such as camper or mobile water systems.
Specifications
| Brand | Jabsco |
| Range | Parmax |
| Max Flow Rate | 15.1 LPM | 4 USGPM |
| Self Priming Capability | 2.4 Metres |
| Temperature Range | 0 - 60°C | 32 - 140°F |
| Pump Size | 13mm | 1/2" |
| Port Fittings | 2 x 1/2" (13mm) Straight Hosebarb |
| Max Operating Pressure | 40 PSI | 2.8 bar |
| Max Inlet Pressure | 30 PSI | 2.1 bar |
| Voltage | 12v |
| Diaphragm Material | Santoprene |
| Check Valve Material | EPDM |
| Fuse Size | 15 (amp) |
| Packaged Dimensions | L:39.4 x H:15.2 x W:14 cm |
