Attention: This is a outdoor Yagi antenna only. It doesn't work alone. You need a Cell Phone Signal Booster/Repeater to work with this antenna.
1. Broad band, Stable performance
2. Low VSWR, High gain
3. Support the popular communications system currently
1. GSM/EGSM/CDMA800/3G/WLAN/WiMax/AWS
2. Wireless Communications and data transmission system Repeater
Specification:
Frequency rang-MHz | 698-2700MHz |
Bandwidth -MHz | 698-2700MHz |
Gain -dBi | 9db |
element | 6 |
beam width -° | H：36 V：32 |
F/R ratio-dB | ≥15 |
VSWR | ≤1.5 |
Input Impedance-Ω | 50 |
Polarization | Horizontal or Vertical |
Max power -W | 100 |
Lightning protection | DC ground |
Connector type | N-male |
Size-mm | 470*190*26 |
Weight-g | 400 |
FAQ
1. What does a mobile phone signal booster include? How does it work? Can I use the signal booster when the outdoor signal has 0 bar?
1) A signal booster kit mainly includes a signal amplifier ,an outdoor antenna(with a 10 meters coaxial cable ), and an internal antenna(with a 5 meters coaxial cable) etc.2) Outdoor antenna receives the signal from the base station to transmit to the repeater, the signal is boosted around the place via the indoor antenna to improve the call; It is suitable for transmitting the voice and data of mobile phone, tablet PC, or the Internet.
3) Signal booster can only boost the mobile phone network signal, but does not help to generate any signal. For example, if your outside signal has 0 bar, it can not work or bring you any signal.
2. My outside signal only has 1 bar, the booster can bring me signal?
Yes, it can. According to this situation, you need a higher dB gain booster (80dB gain)+ a higher dbi outdoor LPDA antenna+ a higher dbi indoor wall panel antenna. You can contact our customer service to get related information.3. What do I need to know before ordering a signal booster?
Before ordering, you need to know your network operator frequency. Every network operator has its own technology and frequency. The signal booster can only work well when it is suitable for your network frequency, otherwise it would not boost any signal.4. I do not know my network frequency? How can I know it?
Before ordering, you can search the frequency site or call your network operator to get information:Other choice: contact the customer service to provide related information to recommend.
A. Tell us your network operator ,and it is used in which country.
B. Tell us network current signal type(2g 3g or 4g)
C. Tell us to use it to transmit voice or data
5. How can we do if we order the wrong frequency booster?
You can contact the customer service to get the solution.6. Why is my signal still same after installing the booster kit?
A. The booster frequency is not suitable for your mobile phone network frequencyB. The booster or the antenna is broken down
7. Mobile phone has full signal with booster, but can not make call or send message?
Maybe it is the signal input and signal output interfere with each other. You need make sure:There is separate wall between indoor and outdoor antenna, so that the two antenna signal do not interfere with each other.
Please try to change the direction of outdoor antenna.
8. What square meters signal will the booster cover？
According to the house construction, material, outside signal, etc., it can boost signal as much as 2000 square meters. More information, you can contact the customer service.9. About receiving the incomplete parcel?
Please contact the customer service to solve, do not leave the negative feedback, open return or case request.10. Why can I get a signal on my mobile phone outside but not inside of house?
Houses are built with much reinforced concrete, roof is with heat shield , or the outside walls are backed with foil. That metal which is used in many construction materials or the metal construction acts as a total barrier for mobile phone signals. In this case, the signal booster can work and play an important role.11. What is the difference of different outdoor antennas?
For area with good outdoor signal strength, you will need the standard Omni directional antenna which does not need to be pointed at the local mast asit receives and broadcasts the signal in all directions, such as the omni tube antenna ,the fiber glass antenna, etc. If the outdoor signal is weak, you need the outdoor directional antenna which should be pointed to the base station to get signal, such as the outdoor yagi antenna, the outdoor LPDA antenna, etc.12. What is the difference of different indoor antennas?
The right angle antenna is the plug and play antenna, and it does not have cable, but convenient to install, suitable for the area around 100 square meters. The indoor ceiling antenna and the indoor wall panel antenna have 5 meters cables, more flexible, 4-6 of these antennas can be connected to one booster standalone to bring signal around 4-6 rooms, which covers signal around 2000 square meters, especially suitable for the large area such as factory, company office, multilayer building, etc.(1) Usually we ship item by Australia Post Service within 2 working days after full payment is received(except weekends and holidays).
