Description
BRAND NEW IN BOX
Images are representative. Actual products may vary.
Fitment
1997-2001 For Acura Integra Type-R 1.8L DOHC B18C5 VTEC
Includes:
CP-Carrillo Forged Custom Pistons For Acura B18C5 Integra Type R Bore 81mm 10.0:1 CR
Manley "H" Beam Steel Connecting Rods
Cometic .030" MLS Cylinder Head Gasket (Ask us about different thickness options)
ACL STD Size Main & Rod Bearings & Thrust Washer
ARP Head Stud Kit
CP-Carrillo Forged Custom Pistons
Bore: 81mm
CR: 10.0:1
Fitment
1997-2001 For Acura Integra Type-R 1.8L DOHC B18C5 VTEC
Includes:
CP-Carrillo Forged Custom Pistons For Acura B18C5 Integra Type R Bore 81mm 10.0:1 CR
Manley "H" Beam Steel Connecting Rods
Cometic .030" MLS Cylinder Head Gasket (Ask us about different thickness options)
ACL STD Size Main & Rod Bearings & Thrust Washer
ARP Head Stud Kit
CP-Carrillo Forged Custom Pistons
Bore: 81mm
CR: 10.0:1
Features:
- Dedicated forgings
- Balanced to + or 1 gram
- Wrist pins provided at no cost
- Pin fitting provided at no cost
- Accumulator Grooves
- Dual forced pin oilers
- Pick lock grooves
- Fully CNC machined
Manley "H" Beam Steel Connecting Rods
Manley "H" Beam connecting rods are manufactured from 4340 forgings to the same exacting standards developed and approved by our original equipment customers. There is a vast difference in quality between a Manley "H" Beam and the "other" inexpensive H-Beams on the market. Weight matched to +/- 1.5 grams. Perfectly round big and small ends. Bend and twist is tightly controlled. 3/8" ARP 2000 Cap fasteners.
Manley "H" Beam Steel Connecting Rods
Manley "H" Beam connecting rods are manufactured from 4340 forgings to the same exacting standards developed and approved by our original equipment customers. There is a vast difference in quality between a Manley "H" Beam and the "other" inexpensive H-Beams on the market. Weight matched to +/- 1.5 grams. Perfectly round big and small ends. Bend and twist is tightly controlled. 3/8" ARP 2000 Cap fasteners.
| ITEM SPECIFICS | |||
| Condition: | New | Brand: | Manley Performance |
| Big End Width: | 0.858 | Manufacturer Part Number: | 14026-4 |
| Gram Weight (avg): | 500 | Engine: | B18C |
| Rod Bolt: | 3/8" ARP 2000 | Vehicle Make: | For Acura |
| Beam Type: | H-Beam Rods | Pin Size: | 21mm (.827") |
| Big End Bore: | 1.89" | Rod Length: | 5.433" (C to C) |
| Product Weight: | 500 | Material: | 4340 Steel |
Cometic MLS Cylinder Head Gasket
Thickness: .030" (Different thickness options are available, please contact us for details)
Bore: 81.5mm
COMETIC MLS (Multi-Layer Steel) Head Gaskets provide maximum sealing performance for today's high output engines and require no sealants. MLS gaskets are ideal for both aluminum heads to aluminum blocks and aluminum heads to cast iron blocks. They can withstand the shearing force created by the two materials. MLS gaskets have increased strength because they are comprised of multiple layers of stainless steel; which also creates the ability to rebound and resist corrosion. The outer layers are embossed and coated on both sides with Viton (a flouroelastomer rubber based material that is heat resistant to 250 C/ 482 F). Viton is designed to meet the demands of a variety of harsh sealing environments, load conditions, and surface finishes. The center or shim layer is uncoated stainless steel, which can be varied to accommodate multiple thickness requirements.
ACL STD Size Main & Rod Bearings & Thrust Washer
ENGINE BEARINGS
CON ROD BEARING SET
MAIN BEARING SET
Part# Part# 4B1925H
5M1959H
Sizes STD
STD Oil Clearance Standard
Standard Half Type Identical Halves Upper & Lower Material
Tri-metal Hardened steel backs
Tri-Metal Min Std Shaft Size
1.7707" / 44.976mm
2.1646" / 54.980mm
Max Std Shaft Size
1.7717 / 45.000mm
2.1654" / 55.000mm
Min Std Tunnel Size
1.8898" / 48.000mm
2.3228" / 59.000mm
Max Std Tunnel Size
1.8898 / 48.000mm
2.3236" / 59.020mm
Max Wall at Crown
0.0591" / 1.502mm
0.0790" / 2.007mm
Max Overall Length
0.689" / 17.50mm
0.787" / 20.00mm
Notes
THRUSTWASHER SET Part# 1T1957 Material Aluminum Tin Sizes STD Notes Identical Halves
ARP Head Stud Kit
Specifications Socket Size(s) 1/2 12pt, 3/16 Allen
Cometic MLS Cylinder Head Gasket
Thickness: .030" (Different thickness options are available, please contact us for details)
Bore: 81.5mm
COMETIC MLS (Multi-Layer Steel) Head Gaskets provide maximum sealing performance for today's high output engines and require no sealants. MLS gaskets are ideal for both aluminum heads to aluminum blocks and aluminum heads to cast iron blocks. They can withstand the shearing force created by the two materials. MLS gaskets have increased strength because they are comprised of multiple layers of stainless steel; which also creates the ability to rebound and resist corrosion. The outer layers are embossed and coated on both sides with Viton (a flouroelastomer rubber based material that is heat resistant to 250 C/ 482 F). Viton is designed to meet the demands of a variety of harsh sealing environments, load conditions, and surface finishes. The center or shim layer is uncoated stainless steel, which can be varied to accommodate multiple thickness requirements.
ACL STD Size Main & Rod Bearings & Thrust Washer
| ENGINE BEARINGS | ||||
CON ROD BEARING SET |
MAIN BEARING SET | |||
| Part# | Part# | |||
| 4B1925H | 5M1959H | |||
| Sizes | STD | STD | ||
| Oil Clearance | Standard | Standard | ||
| Half Type | Identical Halves | Upper & Lower | ||
| Material |
Tri-metal Hardened steel backs | Tri-Metal | ||
| Min Std Shaft Size |
1.7707" / 44.976mm |
2.1646" / 54.980mm | ||
| Max Std Shaft Size |
1.7717 / 45.000mm |
2.1654" / 55.000mm | ||
| Min Std Tunnel Size |
1.8898" / 48.000mm |
2.3228" / 59.000mm | ||
| Max Std Tunnel Size |
1.8898 / 48.000mm |
2.3236" / 59.020mm | ||
| Max Wall at Crown |
0.0591" / 1.502mm |
0.0790" / 2.007mm | ||
| Max Overall Length |
0.689" / 17.50mm |
0.787" / 20.00mm | ||
| Notes | ||||
| THRUSTWASHER SET | ||||||||||||||
| ||||||||||||||
| Specifications | |
|---|---|
| Socket Size(s) | 1/2 12pt, 3/16 Allen |
