SIIG Mini DisplayPort 1.2 to 4K HDMI/DVI/VGA Conversion Adapter (CB-DP1H11-S1)

Brand New Fast & Free Shipping

Features:

• Simply connects the Mini DisplayPort output of tablet or laptop computer to either a HDMI, DVI or VGA equipped display device
• Works with one connected output at a time
• 3-in-1 converter solution expands the compatibility between Mini DisplayPort and most mainstream displays without requiring an additional adapter
• Supports DisplayPort 1.2 protocols includes 48-bit color depth, high bite rate (up to 21.6 Gbps) and maximum video resolution up to 4Kx2K (30Hz) on HDMI output
• Compact and lightweight design makes it a perfect solution to use at home, in the office, or on the road
• No driver installation required
• Supports audio out through HDMI connection only
• Bus-powered, no external power source required

Specifications:

• Chipset: ANX9833 + PS8339B
• Supports Mini DisplayPort v1.2 Dual-mode input
• Supports DisplayPort v1.2, for 1.62 Gbps, 2.7 Gbps, 5.4 Gbps link rates
• Resolution:
  • HDMI: Up to 4Kx2K @ 30Hz
  • DVI: Up to 1920x1080 @ 60Hz
  • VGA: Up to 2048x1152 @ 60Hz
• Product:
  • Length (embedded cable): 10.0" (2550±20mm)
  • Dimensions (case only): 3.44" (W) x 1.77" (H) x 0.59" (D)
  • Weight: 0.11 lbs
  • Color: White
  • Material: Plastic
• Connectors:
  • 1, 20-pin, Mini DisplayPort, Male, Input
  • 1, 19-pin, HDMI, Female, Output
  • 1, 25-pin, DVI-D, Female, Output
  • 1, 15-pin, D-sub VGA, Female, Output
• Environmental conditions:
  • Operating temperature: 32 to 113 degrees F
  • Storage temperature: 14 to 158 degrees F
  • Relative humidity: < 85% non-condensing
• Certifications/Standards: FCC, CE, RoHS
• Warranty: 2 years limited
• Country of origin: China

Requirements:

• Computer with an available Mini DisplayPort 1.2 output (Mini DisplayPort converter/adapters not supported)

Package Contents:

• Mini DisplayPort 1.2 to 4K HDMI/DVI/VGA Conversion Adapter
• User reference guide
