15 Pin Female D-SUB
Solder Connectors / Plastic Hoods

  • Choice of items:
  • Black Hood & 15 Pin DB15 (DA15) Female Solder Connector
  • Black Hood
  • 15 pin DB15 (DA15) Female solder connector
  • Grey Hood & DB15(DA15) Female Solder Connector
  • Grey Hood & DB15(DA15) Female Solder Connector with Jack Posts

EXACT PARTS AS PICTURED IN PHOTOGRAPH (Pack qty is one)

 Main picture shows all available types , you will only receive the type you select from the drop down selection
Picture changes to the specific item you will receive when you make the selection from the drop down box

(Pack qty is one)










SPECIFICATION of Black HOOD (Backshell):

Manufacturer:     Part No: MC-DPPK15

Material

Black Nylon  (Polyamide), Hinged single piece with retaining latches

Temperature Range

-55ºC to +105ºC

Cable Strain Relief

Cable Clamp with self-tapping screws

Cable Diameter

3mm to 11mm   -  Straight Exit

Locking Screws

 Long Thumb jackscrews, moulded top for colour coding UNC 4-40

 Size:  Depth        =15mm

          Length (B) = 30.8mm
          Width   (A) = 40.7mm


Commonly called: DB15
Technical size:     DA15





SPECIFICATION of GREY HOOD (Backshell):


Material

Grey two-part thermoplastic, screw & nut bolt together. UL94HB material

Temperature Range

-55ºC to +105ºC

Cable Strain Relief

Internal two-part cable clamp type

Cable Diameter

5mm to 10mm



Straight Exit

Locking Screws

Long Thumb jackscrews,

UNC 4-40

 Size:  Depth        =17.3mm

          Length (B) = 36.5mm
          Width   (A) = 39.6mm



Commonly called: DB15
Technical size:     DA15




SPECIFICATION of CONNECTOR



 Connector Series

 D-Subminature

 Size of Connector

 Commonly called DB15   (technical size DA15)

 Solder Bucket terminations

 Configured in two rows (1 x 7 , 1 x 8 )

 Current Rating Per Terminal

  1 Amp

 Voltage Rating

 250 V

 Front face size:

 39.14mm x 12.5 mm
