Anti Surge GT3582 GT35 T3 Flange AR 0.63 Water Turbo + 3" 76mm Intercooler Pipe

Description



Notice:

Pick up service is not available.

This turbo is an universal application turbo, some modification may be required based on individual vehicle. Please check the details carefully before purchasing.
3" 76mm Aluminum Universal Intercooler Turbo Piping Pipe Kit fits all Turbo Projects.

Application
Perfect for all 4/6 cylinder and 3.0L-6.0L engines
Horse Power: Capable of Boosting Horse Power up to 600HP
Cooling Type: Water + Oil

Specification

Turbine Side:
Exhaust Inlet Flange: T3 Flange
Exhaust Outlet Flange: 4-Bolt
Turbine Trim: 84.2
Turbine A/R: 0.63
Turbine Inducer Diameter: 68mm
Turbine Exducer Diameter: 62.4mm

Compressor Side:
Compressor Trim: 56.9
Compressor A/R: 0.7
Compressor Inducer Diameter: 61.5mm
Compressor Exducer Diameter: 81.5mm
Compress Inlet Size(Air intake): 4 inch (103.5mm)
Compressor Outlet Size: 2.5 inch (63.6mm)

Bearing Type: Floating/Journal Bearing
Thrust bearing: 270 degree
Cooling Type: Water + Oil Cooling
Horse Power: Up to 600HP
Turbo Type: Individual
Universal Fitment: Yes
Finish:Matte
Wastegate:Without Wastegate
Oil feed/inlet: M10*7/16-24
Oil Outlet: M14.1 & 2*M8*1.25
Water inlet/outlet: M14* 1.5
Maximum PSI: 22
Condition: Brand New
Pakage Size: 26 x 25 x 23 cm
Pakage Weight: 8350g


Package Including

2x 90 Degree Aluminum Pipe 3"
2x Straight aluminum pipe 3"
2x 45 Degree Aluminum Pipe 3"
2x U Aluminum Pipe 3"
8 x high tempature silicone hose: (6x straight, 2 x 90degree) Blue
16x T-bolt Clamps
Turbo and gaskets

Description
Pipe Thickness: 1.8mm
Pipe length: 18''

Condition
Brand New
Notice
* Please check the specifications carefully before bidding. If you are not sure about these information, please feel free to contact us
* This is universal application turbo, so modification might be required for some vehicles
* Professional installation is highly recommended (No Instruction Included)
