Application

For Ford Sierra RS Cosworth (1986–1990) – Fits YB 2.0L Turbo engine
For Ford Escort RS Cosworth (1992–1995) – Fits YB 2.0L Turbo engine

Specification

Beam Style: H-beam Street/Strip
Material: 4340 Chromoly Steel
Finish: Shot-peened
Wrist Pin Style: Floating
Clearanced for Stroker: Yes
Cap Retention Style: Through-bolt
Connecting Rod Bolt Brand: ARP
Connecting Rod Bolt Diameter: 3/8"
Connecting Rod Bolt Material: Alloy Steel
Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
Connecting Rod Bolt Head Style: 12-point
CNC Machined: High Precision
Rod Cap Alignment: Precision dowels
Bore Tolerance: ±0.005 mm
Balancing: ±1 gram per rod
Weight Matched Set: Yes
Remanufactured: No
Testing: Magnafluxed, X-rayed, Ultrasonically tested
Heat Treated: Yes

Dimensions

Connecting Rod Length Center to Center: 136.50mm/5.374in
Approximate Connecting Rod Weight:595g
Big End Bore Diameter: 55.00mm/2.165in
Pin End Bore Diameter: 24.00mm/0.945in
Big End Width: 25.90mm/0.020in
Small End Width: 25.90mm/0.020in

Performance Ratings

Advertised Horsepower Rating: 200HP/piece
Advertised RPM Rating: 9000rpm

Packaging

Quantity: Sold as a set of 4
Package Size: 28CM*20CM*10CM
