Compact, rugged IP65 tracker with LoRa and Bluetooth radio, GPS and sensors - ideal for off-grid communication, tracking and monitoring. Works with the open Meshtastic platform.
Key Features
- Protocols Supported: LoRa, Bluetooth 5.x (NRF52840 + LR1110)
- Precise GPS: Mediatek AG3335 for accurate positioning
- Interfaces: 4 Pogo Pins, USB for Firmware Updates, Logging & API
- Sensors: Temperature, Brightness, 3-Axis Accelerometer
- Display & Operation: 1 LED, 1 Buzzer, 1 Button
- Built-in Antennas: GNSS / LoRa / Wi-Fi / BLE
- Range: about 2-5 km (depending on antenna, mounting, environment)
- Protection class: IP65, suitable for outdoor use
- Temperature Range: -20 to +60°C, Resolution 0.1°C
- Dimensions: 85 × 55 × 6.5mm
- Weight: 32g
- Humidity: 5-95% (non-condensing)
- Battery: 700mAh Li-ion, monitored battery level message via uplink
- Charging: USB magnetic charging cable (1m, power adapter not included), 4.7-5.5V
- Charging Temperature: 0 to +45°C
- Certifications: CE / FCC
- Asset Tracking: Track position and movement, including environmental data
- Outdoor & Adventure: Offgrid communication in the team, location sharing via Meshtastic app
- Environmental monitoring: measurement of temperature and brightness in remote areas, such as for weather data or conservation projects
