LEUZE ELECTRONIC CSL505-R50-1550-M8 / CSL505-T50-1550-M8 SAFETY LIGHT CURTAIN RECEIVER/TRANSMITTER

LEUZE ELECTRONIC CSL505 Safety Light Curtain Receiver & Transmitter

The LEUZE ELECTRONIC CSL505 Safety Light Curtain system consists of receiver model CSL505-R50-1550-M8 and transmitter model CSL505-T50-1550-M8. Designed for precise object detection, this system ensures reliable and accurate monitoring in industrial automation and safety applications.

Manufacturer: LEUZE ELECTRONIC
Type: Safety Light Curtain Receiver / Transmitter
Receiver Model: CSL505-R50-1550-M8
Transmitter Model: CSL505-T50-1550-M8
Order No.: 50131353 / 50131409
Serial No.: 1642288 / 1642290

Technical Information

• Series: 505
• Application: Precise Object Detection
• Beam Spacing: 50 mm
• Number of Beams: 32
• Protection Height: 1,550 mm
• Operating Range: 0.3 ... 5 m
• Light Source: LED, Infrared
• Wavelength: 860 nm
• Transmitted-Signal Shape: Pulsed
• Min. Object Diameter: 52.5 mm
• Output Type: Digital Switching Output
• Switching Device: Transistor, Push-Pull
• Switching Principle: Light / Dark Switchable
• Supply Voltage: 24 V DC
• Material: Aluminum
• Connection Type: Male Connector M8 4-Pin
• Protection Class: IP65
• Ambient Temperature: -30 ... 50 °C
• Dimensions: 10 x 1,630 x 27 mm
