LEUZE CT30-300S SAFETY LIGHT CURTAIN

Leuze CT 30-300 S Safety Light Curtain, Transmitter

The Leuze CT 30-300 S is a high-performance safety light curtain transmitter designed for industrial safety applications. With a sensing range of 0.8 to 18 meters and a protection height of 300 mm, it offers excellent detection capability and reliable protection for machine safety.

Manufacturer: LEUZE

Type: Safety Light Curtain, Transmitter

Model: CT 30-300 S

Order No.: 563303

Technical Data:

• Sensing Range: 0.8 “ 18 m
• Protection Height: 300 mm
• Detection Capability: 30 mm
• Supply Voltage: 24V DC
• Type: 4, IEC 61496
• Current Consumption: 75 mA
• Degree of Protection: IP65
• Ambient Temperature: 0 to 55 °C
• Type of Connection: Cable with connector, 8-pin, M12
• Housing Material: Aluminum
