Application:

This motor is perfect for a wide range of applications, including water pumps, sprayers, harvesters, and grinders. Whether for agricultural or industrial use, this motor meets your needs and supports your projects with dependable performance.

Specification:

Enclosure Type: Open Drip Proof (ODP) Enclosure

AC Phase: Single Phase

Rated Load (HP): 1HP

Rotational Speed：3450RPM

Frequency Rating：60 Hz

Nominal Rated Input Voltage：115/230 V

IEC Frame Size：56C

 Service Factor: 1.15.

Full Load Amps: 13.5/7.0A

INS.CL: F

Reversible/Non-Reversible：Non-Reversible

CCW Rotation Facing Shaft

Thermally Protected

Overall Length With Shaft: 12.4"

 Overall Height: 8.27"

Overall Width: 9.06"

 Shaft Diameter: 5/8"

Shaft Type:Keyed

Shaft Length: 1.88"

Standard Size Keyway: 3/16"

Features: Manual Reset Overload Protection

Package included:

1x Electric Motor

1x Manual

Note:

Suggest using in clean and dry environments. Made of high-quality steel material, it can protect the engine, longer service life.
