Specification:

• Material: 40CR Steel

• Handle Length: 370mm (approx.)

• Drive Size: 3/8" Square Drive

• Socket Fitting Material: Fully Hardened & Tempered Steel

• Torque Range: 13.6 - 108.5 Nm / 10 - 80 Ft-Lb

• Drive Mechanism: Heat Treated CR-MO with 72T Gear

Package included:

1 x 3/8" Drive Click Torque Wrench

1 x 75mm 3/8" Drive Extension Bar

1 x 3/8" to 1/2" Drive Adapter

1 x 3/8" to 1/4" Drive Adapter

1* Maunal

1* Storage Case

Showing as the picture

Features:

• Accurate & Reliable: Professionally tested and pre-calibrated to ±4%. Includes a thickened plastic storage box for protection.

• Laser Engraved Scale: Features a dual-range laser-engraved scale for permanent visibility and easy identification, enabling precise torque adjustments.

• Sturdy Construction: Built with a steel body and a hardened Chrome Vanadium (CRV) steel 45-tooth ratchet head for durability and reliability.

• User-Friendly: Easy to operate—listen for the "click" to confirm the preset torque has been reached. Includes a quick switch button for added convenience.

• 72T Gear: The 72-tooth gear ensures smoother meshing, higher transmission accuracy, reduced operational noise, and improved efficiency.

Usage Notes:

• If the wrench has not been used or has been stored for some time, operate it several times at a low torque setting to allow the internal lubricant to re-coat working parts.

• When not in use, always store the wrench set to the lowest torque setting.

• Do not adjust the handle below the lowest torque setting.

• Do not continue pulling after the preset torque is reached and the wrench releases. Release pressure immediately to allow automatic reset—continuing to apply pressure may damage components by exceeding specified torque.

How to Use:

1. Hold the wrench with graduations visible and the marked arrow/elementary scale facing up.

2. Unlock the knurled handle by turning the lock nut counterclockwise.

3. Set the required torque by turning the knurled handle to the exact value shown on the scale graduations.
