Pioneer 4 Channel Car Audio Amplifier 1000w Max Bridgeable 4 x 170w GM A6704
Pioneer 4 Channel Car Audio Amplifier 1000w Max Bridgeable 4 x 170w GM A6704
Price:
£149.99
Pioneer GM-A6704 4 Channel 1000W Bridgeable Amplifier for Speakers / Subwoofer
The Pioneer GM-A6704 is a powerful 4-channel car amplifier designed to upgrade the performance of your vehicle’s audio system. With strong output power, flexible installation options and advanced sound tuning features, this amplifier can easily drive multiple speakers or power a subwoofer when bridged. Built with a durable chassis and a high-quality internal power supply, it delivers clean sound, strong bass and reliable performance.
- 4-channel bridgeable car amplifier
- Maximum power output up to 1000W when bridged
- 60W RMS per channel for clear speaker performance
- 190W RMS bridged output for subwoofer setups
- Variable high-pass and low-pass filters for precise tuning
- Adjustable bass boost (0 – 12 dB)
- Automatic signal sensing turn-on function
- Speaker-level inputs for factory stereo compatibility
- Wide frequency response for detailed audio playback
- High signal-to-noise ratio with low distortion
Powerful 4-Channel Amplification
The GM-A6704 delivers 60W RMS per channel to power your front and rear speakers with clear and detailed sound. When bridged, the amplifier can provide up to 190W RMS to drive a subwoofer or a pair of high-performance speakers.Flexible System Configuration
This amplifier allows multiple installation setups. You can power four speakers, run front speakers while bridging rear channels for a subwoofer, or use 2-channel mode to send higher power to component speakers or subwoofers.High-Quality Power Supply
The amplifier features an advanced internal power supply designed to maintain stable power delivery even during demanding bass-heavy playback. This improves sound dynamics and reduces distortion.Automatic Signal Sensing
When connected to factory audio systems without RCA outputs, the amplifier can automatically power on when it detects an audio signal through the speaker-level inputs. This allows easy integration with OEM head units.Adjustable Bass Boost
The built-in bass boost control lets you enhance low frequencies with adjustable levels between 0 and 12 dB at 50 Hz, allowing you to tailor the bass response to your music preferences.Advanced Crossover Filters
Channel A includes a variable high-pass filter from 40 Hz to 500 Hz or a fixed low-pass filter at 80 Hz for detailed tuning. Channel B features selectable high-pass or low-pass filtering at 80 Hz, helping optimise sound for speakers or subwoofers.Durable Amplifier Design
The amplifier uses a solid chassis and effective heat dissipation to maintain stable performance during extended listening sessions, ensuring long-term reliability.Specifications
| Amplifier Type | 4 Channel Bridgeable Amplifier |
| Class | Class A/B |
| Maximum Power Output | 1000W Bridged / 170W x4 (4Ω) / 250W x4 (2Ω) |
| Continuous Power Output (RMS) | 60W x4 (4Ω) / 95W x4 (2Ω) / 190W x2 (4Ω Bridged) |
| CEA 2006 Power | 4 x 60W (4Ω) |
| Speaker Impedance | 2 – 8 Ohm (Stereo) |
| Frequency Response | 10Hz – 70kHz (+0dB / -3dB) |
| Total Harmonic Distortion | < 0.05% |
| Signal to Noise Ratio | > 95 dB |
| Bass Boost | 50 Hz (0 – 12 dB) |
| High Pass Filter | 40 – 500 Hz (-12 dB/oct) |
| Low Pass Filter | 40 – 500 Hz (-12 dB/oct) |
| Speaker Terminals | Screw-Type |
| Input Sensitivity | 3 – 26 V |
| Power Source | 14.4V (10.8 – 15.1V allowable) |
| Fuse Rating | 25A x 2 |
| Max Current Consumption | 31A |
| Dimensions | 356 x 60 x 215 mm (W x H x D) |
| Unit Weight | 2.2 kg |
| RCA Inputs | 4 Channel |
| Speaker Line Input Sensor | Yes |
| Manufacturer Part Number | GM A6704 |
| Brand | Pioneer |
| Channels | 4 Channel |
| Impedance | 2-8 Ohm |
| Fuse | 25A x 1 |
| Power RMS / Max. - @ 4 Ohm | 60 W x 4 / 170 W x 4 |
| Power RMS / Max. - @ 2 Ohm | 95 W x 4 / 250 W x 4 |
| Low-pass | A/B Ch - 80 Hz |
| Slope Subsonic / Low Pass | HPF - A Ch - 40 Hz to 500Hz,HPF - B Ch - 80Hz |
| Bass Boost | 50 Hz - Frequency |
| RMS @ 4ohm | 60 W x 4 |
| RMS @ 2ohm | 95 W x 4 |
| Frequency Response | 10Hz to 70kHz (+0dB,-3dB) A/B Ch |
| Features | Amplifier |
| Colour | Black |
| Model | GM-A6704 |
| Country of Origin | Japan |
| Unit Type | Unit |
| Unit Quantity | 1 |
| Recommended Fuse | 25 A x 2 |
