Pioneer 10" Subwoofer Speaker System Shallow Mount Car Audio 1300W TS D10LB
Pioneer 10" Subwoofer Speaker System Shallow Mount Car Audio 1300W TS D10LB
Price:
£249.99
Pioneer TS-D10LB 10" Shallow Mount Subwoofer Box – 1300W Max, Slim Sealed Enclosure, 2 Ohm
Key Features
- 10" shallow mount pre-loaded subwoofer system
- 1300W max power / 350W RMS
- Single 2 Ohm voice coil
- Compact sealed enclosure design
- Aramid fiber reinforced IMPP™ cone
- Dual meta-aramid fiber spider (Conex)
- Butyl rubber surround for durability
- Slim profile – fits tight spaces (only 150mm depth)
- Rigid carpeted enclosure with steel mesh grille
- Deep and controlled bass performance
- Flexible mounting positions (under seat, trunk, etc.)
- Optimized for mono subwoofer amplifiers
- CarSoundFit app compatible
Slim & Space-Saving Design
The TS-D10LB is designed for tight installations where standard subwoofer boxes won’t fit. With its shallow enclosure, it can be installed under seats, in small trunks, or compact vehicles without sacrificing bass performance.
Pre-Loaded Sealed Enclosure
The rigid sealed enclosure reduces unwanted resonance and improves bass accuracy. Its carpet finish and steel mesh grille provide protection while maintaining a clean look.
Aramid Fiber IMPP™ Cone
The injection-molded cone reinforced with aramid fibers delivers strength and precision. This ensures tight, punchy bass with reduced distortion even at higher output levels.
Advanced Suspension System
Featuring a butyl rubber surround and dual meta-aramid fiber spider, the subwoofer maintains stable and controlled cone movement, improving sound clarity and long-term durability.
Deep & Controlled Bass
A powerful motor structure with a large voice coil and ferrite magnet ensures strong bass output with excellent control, even during demanding low-frequency playback.
Flexible Installation
The enclosure can be mounted in multiple orientations to suit your vehicle layout, allowing you to optimize bass response based on your setup.
Specifications
| System Type | Pre-Loaded Shallow Subwoofer (Sealed) |
| Series | Pioneer D-Series |
| Size | 10" |
| Max Power | 1300W |
| RMS Power | 350W |
| Frequency Response | 20 Hz – 3.4 kHz |
| Sensitivity | 74 dB |
| Impedance | 2 Ohm |
| Voice Coil | Single Voice Coil |
| Voice Coil Material | Copper |
| Voice Coil Bobbin | Glass Imide |
| Cone Material | IMPP™ Aramid Fiber |
| Surround | Butyl Rubber |
| Spider | Dual Meta-Aramid Fiber |
| Enclosure Type | Sealed |
| Enclosure Dimensions | 530 x 300 x 150 mm |
| Magnet Type | Ferrite |
| Magnet Weight | 43.4 oz |
| Basket Material | Metal |
| Grille | Steel Mesh Included |
| Weight | 7.49 kg |
| CarSoundFit App | Supported |
| Manufacturer Part Number | TS D10LB |
| Brand | Pioneer |
| Placement on Vehicle | Boot |
| Size | 10 in |
| Impedance | 2 O |
| Features | Bass Box, Subwoofer, Ultra Slim |
| Subwoofer Model | TS D10LB |
| Protection grill | Fully Covered Steel Mesh |
| Voice Coils | Single Voice Coil |
| Dust Cap | ABS |
| Surround Type | Rolled |
| Power Handling (RMS / Max) | 350W/1300W |
| Woofer Cone Material | IMPP - Aramid Fiber |
| Mounting Diameter | 140 mm |
| Sensitivity | 74dB |
| Frequency response | 20 Hz - 3.4 kHz |
| Subwoofer Type | Shallow Enclosed (Passive) Subwoofer |
| RMS Power | 350W |
| Voice Coil | Glass Imide Bobbin |
| Surround Material | Rubber |
| Peak Power | 1300W |
| Gasket | Polypropylene |
| Voice Coil Former | Copper |
