Application:
For Chevy LS3 V8 6.100"

Specification:

*Type: Forged 4340 aircraft chrome moly quality steel for racing
*H-beam Conrods Quantity: 8 Pieces as showing in picture
*Bolts: Including ARP 8740 7/16" bolts
*Advertised Horsepower Rating:200HP/piece
*Top acceleration: 9000rpm
*package size：29CM*22CM*14CM

Dimension:

Center to center length:154.95mm/6.100"
Big end diameter:56.51mm/2.225"
Small end diameter:23.99mm/0.945"
Big end width:24.00mm/0.945"
Small end width:24.00mm/0.945"

Feature:
1. Material: Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing；
2. H-Beam design reduces weight without compromising strength；
3.Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers；
4.High precision CNC machined,Precision rod cap alignment dowels；
5.Bores finished to +/- .005mm；
6.Balanced to within +/- 1 g per rod；
7. Each rod is magnetic particle tested to ensure free of flaws；
8.Use X-rayed, sonic tested；
9.Custom Service.

Note:
*Professional installation is highly recommended ；
*Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
