Methane Explosion Gas Detector With Range 0-100%LEL 8m Infrared Remote Control

The link is for CH4 gas detectors with a range of 0-100%. If you need other gases you can contact us.

24V 0-100%

Adapter available (sold separately)

If you need a calibration certificate, please contact us to give you a note. Thank you.

Introduction:

fixed gas detector adopts advanced catalytic gas sensor or electrochemical sensor, which can translate the gas concentration in the air to the digital signal output. The detector working with gas controller can be used to detect gas in refinery, chemical plant, LPG station, boiler room, painting plant and other places with gas exists.

Features:

Product type	fixed gas detector/transmitter
Explosion proof grade	Exd ⅡC T6 Gb
Response time	≦30S
Power supply	DC24V±10%
Working temperature	-20℃～50℃
Output current	4-20mA
Working humidity	0-95%RH
Contact output	Free contact output, max power 1kW
Single input	4~20mA and RS485
Installation method	Wall-mounted
Shell material	Aluminum
Dimensions	190x150x95mm（L×W×H）

Specification:

Model	Range	Resolution	L-alarm	H-alarm
CO	0-1000ppm	1ppm	50ppm	150ppm
O2	0-30%vol	0.1%vol	19.5%vol	23.5%vol
H2	0-1000ppm	1ppm	50ppm	150ppm
H2S	0-100ppm	0.1ppm	10ppm	20ppm
CH4	0-100%LEL	1%lel	20%LEL	50%LEL
C2H4O	0-100ppm	1/0.1ppm	20ppm	50ppm
EX	0-100%LEL	1%lel/1%vol	20%LEL	50%LEL
C3H8	0-100%LEL	1%lel/1%vol	20%LEL	50%LEL
C2H5OH	0-100%LEL	1%lel/1%vol	20%LEL	50%LEL
NH3	0-100ppm	0.1/1ppm	20ppm	50ppm
CL2	0-20ppm	0.1ppm	5ppm	10ppm
O3	0-10ppm	0.1ppm	2ppm	5ppm
SO2	0-20ppm	0.1/1ppm	5ppm	10ppm
PH3	0-20ppm	0.1ppm	5ppm	10ppm
CO2	0-5000ppm	1ppm/0.1%vol	1000ppm	2000ppm
NO	0-250ppm	1ppm	50ppm	150ppm
NO2	0-20ppm	0.1ppm	5ppm	10ppm
HCN	0-50ppm	0.1/0.01ppm	10ppm	20ppm
HCL	0-20ppm	0.001/0.1ppm	5ppm	10ppm
CH2O	0-20ppm	1/0.1ppm	5ppm	10ppm
HF	0-100ppm	0.01/0.1ppm	2ppm	5ppm
C7H8/C8H10	0-20ppm	0.01/0.1ppm	5ppm	10ppm

Note: Not all gases and range are listed, if you need more information, please contact us.
