BINDER 713 99 1430 822 04 FEMALE ANGLED CONNECTOR

Binder 713 99143082204 “ Female Angled Connector

The Binder 713 99143082204 female angled connector is a high-quality, durable connector designed for industrial and electronic applications. With a wide range of features, including IP67 protection and screw-locking mechanism, this connector ensures secure and reliable connections in demanding environments.

• Manufacturer: Binder
• Type: Female Angled Connector
• Part No: 713 99143082204
• Ref. No: 14171214079

Technical Information:

• Rated Voltage: 250 V AC/DC
• Rated Impulse Withstand Voltage: 2500 V
• Rated Current: 4 A
• Pollution Degree: 3
• Type of Locking: Screw locking
• Orientation: Angled
• Pin No.: 4 poles
• Protection Class: IP67
• Connection Cross-Section: Max. 0.75 mm² / AWG 18
• Cable Passage: 6 to 8 mm
• Thread Size: M12
• Torque: 0.4 Nm
• Type Standard: DIN EN 61076-2-101
• Rotation Option: 90 degrees (4 coding options)
• Limit Temperature: -40 to 85 °C
• Mechanical Life: Greater than 100 mating cycles
