Product Description
Technical Specifications
|
General
|
|
|
|
Frequency Range
|
RX :
18M-620MHz
840-1000MHz
TX:
18-64MHz
136-174MHz
400-480MHz
|
|
|
Output Power
|
10 watts
|
|
|
Working Voltage
|
7.4V DC
|
|
|
Frequency Stability
|
±2.5ppm
|
|
|
Antenna Impedence
|
50 Ω
|
|
|
Working Temperature
|
-20℃ to +60℃
|
|
|
Battery Capacity
|
2400 mAh
|
|
|
Dimension
|
148 X 63 X 38mm
|
|
|
Weight
|
305g
|
|
|
Transmitter
|
|
|
|
Analog Mode
|
F3E
|
|
|
Modulation Frequency Deviation
|
≤ 5KHz(25KHz)
≤ 2.5KHz(12.5KHz) |
|
|
Modulation Distortion
|
≤7%
|
|
|
Channel Spacing
|
12.5KHZ
|
|
|
Adjacent Channel Power
|
≤ -65dB(W),-60dB (N)
|
|
|
Receiver
|
|
|
|
Sensitivity (12dB SINAD)
|
≤ 0.18 µ V (W)
≤ 0.22uV(N) |
|
|
Audio output power
|
1W
|
|
|
Audio distortion
|
Audio distortion
|
|
|
Spurious power
|
≤ 7.5uW
|
|
Other questions, please contact our custom service, Many thanks.
