ELAU PacDrive MC-4/11/10/400 SERVO DRIVE

Elau MC-4/11/10/400 Servo Drive

The Elau MC-4/11/10/400 Servo Drive is a high-performance motion control unit designed for precise and dynamic automation tasks. Part of the PacDrive MC-4 series, it delivers reliable servo control, efficient power management, and robust performance for demanding industrial applications.

Manufacturer: Elau
Type: Servo Drive
Model: MC-4/11/10/400
Part No.: 13130247 / 943322.0020 2510
SW: 00.22.21
HW: E0P603

Technical Information

• Range: PacDrive
• Series: MC-4
• Control Voltage: 24 V DC
• Input Voltage: 3 Phase 380 to 480 V AC
• Input Current: 10.2 A
• Input Frequency: 48 to 62 Hz
• Output Voltage: 3 Phase 0 to 480 V AC
• Output Current: 10 A
• Output Frequency: 0 to 600 Hz
• Ambient Temperature: 5 to 45 °C
• Dimensions: 69 x 310 x 260 mm
