SIEMENS 6ES7 131-4BD01-0AA0 ELECTRONIC MODULE

Manufacturer: SIEMENS
Family: SIMATIC S7 FOR ET200S
Type: Digital Input Module
MRN: 6ES731-4BD01-0AA0

No. of Digital Inputs (DI): 4
Input: 24 V DC; -30…+5V for signal “0”; 15…30V for signal “1”(7mA current at 24V)
Supply Voltage: 24 V DC; From Power Module; Reverse Polarity Protection
Current Consumption: 10 mA
Power Loss: Typ. 0.7 W
Output Voltage: Min. L+(0.V)
Rated Output Current: 500 mA
Connectable Encoders: (2-wire BEROS), Max. 1.5 mA
Ambient Temp: -25…+60°C
Isolation: Tested With 500 V DC
Dimensions: 15 x 81 x 52 mm
