Description
Power supply:DC12V
Currency:<100MA
Communication:Weigand 26/34
Card type:13.56MHz MF1 s50/s70 13.56Mhz
Induction Distance:1-5cm
DATA transfer range:Max 80m
Working Temperature:0-70°C
Working Humidity:Less than 80%
Dimension (LxWxH mm):110x80x25
Package:plastic casing &epoxy saturated
Color:black
Weight(kg):0.2
PIN description
Pin | Color | Description |
1 | RED | DC12V |
2 | BLACK | GND |
3 | GREEN | WG data0(RS485+) |
4 | WHITE | WG data1(RS485-) |
5 | YELLOW | BUZZER |
6 | BLUE | LED |
7 | BROWN | Select, No Contact means WG26,Connect to GND means WG34 output |
