Alpine S-Series: The Music Lovers Starter Pack

S-Series 13cm (5”) Coaxial 2-Way Speakers

S2-S50

Newly redesigned and Hi-Res Audio Certified, the Next-Generation S-Series S2-S50 13cm (5”) Coaxial Speakers offer a new standard in entry-level sound performance.

We packed supreme capability into these speakers by using highly effective materials and proprietary design elements. The lightweight woofer cone, crafted from a combination of polypropylene, glass fiber, and mica materials, serves up the essential high output / low distortion sound required for High-Res Audio performance. Alpine S-Series speakers feature increased magnet sizes for more power handling and best mid-bass performance in their category.

The woofer's High Amplitude Multi-Roll (HAMR) surround brings out the best in bass by allowing maximum cone movement. A 2cm (3/4") dome tweeter serves up all the high-frequency detail you've been missing with your factory speakers.

All speakers in the S-Series line have a wide vehicle fitment range and include several adapters and spacers. Using in-line crossovers, these speakers can be installed quick and easy even at home.

Hi-Res Audio Certified

Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status system, the Next-Generation Alpine S-Series Speakers are now Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This new benchmark in sound quality elevates the Next-Gen S-Series Speakers resulting in a more accurate and natural sound at an entry-level price point.

Clean, Accurate Audio

Crafted with a unique combination of Poly Propylene, Glass-Fiber, and Mica Cone materials, the S2-S50 is designed for lightweight construction, high output, and low distortion, giving you a clean and accurate audio experience.

HAMR Surround

Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology is integrated into the speaker design which allows for maximum cone movement, delivering powerful and accurate bass notes.

Extensive Mounting Options

The S-Series S2-S50 is compatible with most 10cm installation locations in various vehicles. The steel basket features several screw brackets for different mounting applications.

Made for S-Series Amps & Subs

The S-Series speakers are designed to perfectly match the Alpine S-Series amplifier and subwoofer line for perfect system building. S-Series components are designed to for customers that want to build a great sounding system without breaking the bank, for a fun and great sounding experience including Hi-Res Audio capabilities.

• Woofer Size: 13cm (5”)
• Integrated 2cm (¾“) Tweeters (Coaxial)
• Hi-Res Audio Certified (up to 40kHz)
• Poly Propylene, Glass Fiber, and Mica Cone Material
• Lightweight Design with High Output and Low Distortion
• High-Amplitude Multi-Roll (HAMR) Surround
• Compatible with KTE-S50G Speaker Grills (sold separately)
• Power Handling
• Peak Power: 170 Watts
• RMS Power: 55 Watts
• Cutout Diameter: 113.4 mm
• Mounting Depth: 49.9 mm
• Mounting Height: 15.9 mm
• Magnet: 80.0 mm
• Frequency Range: 65 Hz - 40 kHz (Hi-Res Audio Certified)
• Impedance: 4 Ohms
• Sensitivity: 87 dB/W

• Alpine S2-S50
• Speaker Wire
• Screws
• Speed clips
• Template and specs on box
