SIEMENS 6AV3 617-1JC20-0AX1 OPERATOR PANEL

Siemens SIMATIC OP17 Operator Panel

The Siemens SIMATIC OP17 Operator Panel is a reliable and high-performance human-machine interface (HMI) solution designed to deliver efficient control and monitoring in industrial automation systems. Engineered for versatility and ease of use, it combines powerful communication options, a clear LCD display, and durable construction to ensure long-term operational stability even under demanding conditions.

Manufacturer: Siemens
Type: Operator Panel
MNR: 6AV3 617-1JC20-0AX1
Series: 6AV3
E-Stand Version: 06
Family: SIMATIC OP17

Technical Information

• Supply Voltage: 24 V DC
• Design of Display: LCD Display
• No. of Lines: 8
• No. of Characters per Line: 40
• No. of Function Keys: 24
• No. of Function Keys with LEDs: 16
• Current Consumption: 0.4 A
• Active Power: 10 W
• Type of Memory: Flash / RAM
• Capacity: 256 kbyte
• Interfaces / Bus Type: 2 x RS232, 1 x RS422, 1 x RS485
• Degree of Protection (Rear): IP20
•
  Ambient Temperature: -25 / 70 °C
• Dimensions: 240 x 204 x 50 mm

The OP17 offers intuitive operation through its 8-line LCD display and 24 function keys, including 16 keys with LEDs for quick visual feedback. Its robust design, wide communication compatibility, and memory capacity make it an excellent choice for machine control, process automation, and production line management. Compact yet powerful, this HMI ensures smooth integration and high reliability in industrial environments.
