Hanwha Techwin SLA-5M4600Q Overview
Customize your PNM-9000VQ multidirectional camera with the WiseNet P Series 5MP 4.6mm Sensor Module & Fixed Lens from Hanwha Techwin. This module integrates a 1/1.8" 5MP CMOS sensor and a 4.6mm fixed lens, enabling the PNM-9000VQ to capture video at up to 2616 x 1976 resolution in a 77.9 x 57.9° field of view. Featuring electrical day/night functionality and 120 dB wide dynamic range, the module is designed to deliver clear images in low-light conditions down to 0.16 lux and to balance exposure in scenes with sharp lighting contrasts.
1/1.8" 5MP CMOS with a 4.6mm fixed focal lens, FoV: H: 77.9?, V: 57.9? for the PNM-9000VQ
- 0.16Lux@F1.6 Color, B/W (5MP lenses)
- Selectable lens options: 3.7 / 4.6 / 7.0mm fixed lens (5MP)
- For PNM-9000VQ Camera Body
- 1/1.8" 5MP Progressive Scan CMOS Sensor
- 2616 x 1976 Effective Pixels
- Minimum Illumination: 0.16 Lux
- Electrical Day/Night
- 4.6mm Fixed Lens with f/1.6 Aperture
- 77.9 x 57.9° H/V Field of View
- 120 dB Wide Dynamic Range
Customize your PNM-9000VQ multidirectional camera with the WiseNet P Series 5MP 4.6mm Sensor Module & Fixed Lens from Hanwha Techwin. This module integrates a 1/1.8" 5MP CMOS sensor and a 4.6mm fixed lens, enabling the PNM-9000VQ to capture video at up to 2616 x 1976 resolution in a 77.9 x 57.9° field of view.
Hanwha Techwin SLA-5M4600Q Specs
Video
Sensor | 1/1.8" 5 MP Progressive Scan CMOS |
Total Pixels | 3096 x 2094 |
Effective Pixels | 2616 x 1976 |
Minimum Illumination | At f/2.0, 1/30 Sec, 30 IRE: |
S/N Ratio | 50 dB |
Wide Dynamic Range | 120 dB |
Day & Night | Electrical |
Lens
Focal Length | 4.6mm, Fixed |
Maximum Aperture | f/1.6 |
Field of View (H x V) | 77.9 x 57.9° |
Adjustment Mechanism
Horizontal | -90 to 90° |
Vertical | 50 to 80° |
Rotate | -180 to 180° |
Physical
Housing Material | Plastic |
Dimensions | 1.39 x 1.41" / 35.5 x 35.9 mm |
Weight | 0.08 lb / 35 g |
