Zastone X6 UHF 400-470MHZ Mini portable 16 channels thin handheld walkie talkie portable transceiver walkie talkie
.
|
General |
|
|
Frequency Range |
400-470MHz |
|
Operation Voltage |
DC3.7V |
|
Channel Capacity |
16 |
|
Antenna |
Integrated antenna |
|
Antenna Impedance |
50 |
|
Dimension |
96*55*22mm |
|
transmit |
|
|
Output power |
2W/5W |
|
The maximum deviation |
≤±5KHz |
|
Residual radiation |
<60dB |
|
Current |
≤1000mA |
|
Receiver |
|
|
Sensitivity |
<0.16μV(12dB SINAD) |
|
Squelch Sensitivity |
<0.2μV |
|
Intermodulation |
50dB |
|
Audio Power |
≥300mW |
|
current |
≤100mA |
|
Squelch current |
20mA |
Package units
1X Radio
1xAapter
1xusb Charger
1x User mannual
1XBelt Clip
