Specification:
| DC Supply | |
| ContinuousVoltage Rating | 8 to 35 V Continuous. |
| Cranking Dropouts | Able to survive 0 V for 50mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achineved without the need for internal batteries. |
| Charge Fail/ Excitation | 8 to 35 V fixed power source 2.5W |
| Nominal Standby Current | 23 mA at 12 V, 18 mA at 24 V |
| MAXIMUM OPERATING CURRENT | 35 mA at 12 V, 30 mA at 24 V |
| Outputs | |
| OUTPUT A (FUEL) | 2 A DC at supply voltage |
| OUTPUT B (START) | 2 A DC at supply voltage |
| AUXILIARY OUTPUTS C & D | 2 A DC at supply voltage |
| GENERATOR | |
| VOLTAGE RANGE | 15 V - 333 V AC (L-N) |
| FREQUENCY RANGE | 3.5 Hz to 75 Hz |
| MAGNETIC PICK-UP | |
| VOLTAGE RANGE | ± 0.5v to 70v |
| FREQUENCY RANGE | 10,000 Hz (max) |
| DIMENSIONS | |
| OVERALL | 9.8 cm x 7.9 cm x 4.0 cm |
| PANEL CUT-OUT | 8 cm x 6.8 cm |
| MAXIMUM PANEL THICKNESS | 8 cm |
Feature
• Back-lit icon LCD display
• Front panel editing
• LED and LCD alarm indication
• Power Save mode
• CAN and Magnetic Pick-up/Alt. versions available (specify on ordering)
• PC configurable
• 6 Digital inputs
• 4 Outputs (2 configurable on Magnetic Pick up/Alt., 4 configurable on CAN version)
