General

Frequency Range Receive:

0.5 - 1.8 MHz (BC Band)
1.8 - 30 MHz (Shortwave Band)
30 - 59 MHz (6 Meter Amateur)
59 - 108 MHz (FM)
108 - 137 MHz (Air Band)
137 - 174 MHz (144 MHz HAM)
174 - 222 MHz (VHF-TV)
222 - 420 MHz (ACT1: Action Band 1)
420 - 470 MHz (430 MHz HAM)
470 - 729 MHz (UHF-TV)
803 - 998.99 MHz (ACT2: Action Band 2 Cellular Blocked)

Frequency Range Transmit:

50-54Mhz
136~174Mhz
400 - 470 MHz
(some area & country can be frequency limit)

Channels Memory

Over 1000 Memories

CTCSS CTCSS/DCS

Encode/Decode

Channel Steps

5/9/10/12.5/15/20/25/50/100 kHz

Operating Voltage:

11-16 VDC Negative Ground EXT DC Jack

Operating Temperature

Operating Temperature: -20°C to +60°C

Antenna connect

SMA

Antenna Impedance

50ohms

Dimension (H x W x D)

Case Size: 2.3x3.5x1.1 inches (58x90x29 mm)

Weight

(without knob and antenna) 9.5 oz (270g)

Receiver

Sensitivity:

1.5 μV for 10dB S/N (0.5-30MHz, AM)
1.0 μV for 12dB SINAD (59-108 MHz/470-540MHz, W-FM)
0.5 μV for 12dB SINAD (54-59MHz/300-420MHz, N-FM)

Adjacent Channel Selectivity:

Better than 70 dB

Intermodulation:

Better than 70 dB

AF Output:

0.7W @ 16 Ohms for 10% THD (@ 7.5 V)

Circuit Type:

N-FM, AM Double-conversion, W-FM Triple Conversion

Current Consumption

125 mA (Receive)
8 mA (Auto Power Off)
1500mA (5W)

Transmitter

Power Output

144/430 MHz 5.0/2.5/1.0/0.3 watts
222 MHz 1.5/1.0/0.5/0.2 watts

Modulation Type

Variable Reactance F2D, F3E

Spurious Emission

At least 60 dB down

Modulation Type:

Variable Reactance

Transmit Current

1500mA (5W)

Max. Deviation

±5 kHz

Modulation Distortion

Frequency Stability

Better than ±5 ppm
