This SWR/Watt meter is a highly accurate RF meter for measuring Forward Power, Reverse Power and VSWR.
Main feature:
* Large meter display for easy reading.
* RF power forward reading. Switchable to show the average strength of the Envelope
Power (REP) for SSB and AM transmitters.
* Reflected RF Power Reading.
* VSWR ratio.
* Illumination meter.
* User-friendly control layout for easy operation.
Product : SWR and Power Meter
Brand : Nissei
Type : RS-502
Specification:
* Frequency Range : 1.8 - 525 MHz
* Power Range : 1 - 200 W
* Power Scale : 5/20 / 200 W
* Maximum Power : 200 W
* 5W Accuracy Range:
(AVG) +/- 10%
(REP) +/- 15%
* Accuracy Range 20 - 3 KW :
(AVG) +/- 5%
(REP) +/- 10%
* Minimum Power for SWR : 3 W
* Input / Output Connector: SO-239 (Type M) / PL F
* Weight (Net): 950 g
* Insertion Loss: Less than 0.1db
* Testing Function: FWD / REF POWER, REP, SWR
* Input / Output Impedance: 50 OHM
* Dimensions (L/T/D): 90mm x 85mm x135mm
Packing List :
* NISSEI RS-502 SWR & Watt Meter
*Operating Manual
* 13.8 V DC DC cable
