SRM PM9 Origin Track Carbon Power Meter
The SRM PM9 Origin Track Carbon Power Meter is the latest offering in SRM’s new Origin power meter line. In addition to be highly accurate, this PM9 version features Left/Right Power Balance, Magnet-less cadence, Automatic temperature compensation, and Bluetooth SMART, among other new features. You can order it with either LOOK carbon crank arms, which are the lightest, stiffest cranks SRM offers, or SRM Composite cranks. It’s not cheap, but it’s one of the nicest track power meter cranksets you can buy!
Key Product Details
Compatibility:
This power meter is compatible with 144 BCD 5-bolt track chainrings. It fits 24 MM and 30 MM track bottom brackets, depending on the version ordered.
Power Measurement:
This SRM power meter measures power at the spider and is therefore able to measure power from both legs.
Key Features:
Dual-leg power measurement, carbon crank arms, accurate to within +/- 1.0%, lightweight, rechargeable battery, 100 hours of battery life, left/right power balance, automatic temperature compensation, ANT+ and Bluetooth compatible, 2-year warranty.
Advice From Our Staff:
It’s not cheap, but this is one of the nicest track power meters you can buy. It is accurate, stiff, lightweight, looks great and it comes with a solid 2-year warranty. In addition, with an option to order it with a 24 mm or 30 mm spindle, you can put it on almost any bike.
Options For This Power Meter
Crank Arm:
LOOK-SRM Carbon | SRM Carbon Composite
- LOOK-SRM Carbon – These are the lightest crank arms offered (260 grams). There are two size options: 165/167.5/170 or 170/172.5/175. The crank arms each function in three lengths simply by rotating the Trilobe pedal inserts.
- SRM Carbon Composite – These carbon arms are still very light and stiff, but they weigh a bit more than the LOOK-SRM Carbon at 344 grams per set. However, they are also more affordable.
Spindle:
24 MM | 30 MM
- 24 MM – For use with 24 mm track bottom brackets.
- 30 MM – For use with 30 mm track bottom brackets.
Compatibility
Chainrings: The SRM Origin Track Carbon Power Meter is compatible with 144 BCD 5-bolt track chainrings.
Bottom Bracket: This power meter fits 24 MM or 30 MM track bottom brackets, depending on the version ordered.
In the Box
- SRM Power Meter (spider, crank arms and spindle)
- SRM USB Charger Cable
Specs
| Name | SRM PM9 Origin Track Carbon Fiber |
| Bike Type | Track |
| Location of Power Measurement | Spider |
| Left or Both Legs Measured | Both |
| Independent Left/Right Measurement | Yes - Power Balance |
| Installation | More involved (60 min. estimated) |
| Crank Arm Material | Carbon |
| Communication Protocol | ANT+ and Bluetooth SMART |
| Claimed Accuracy | +/- 1.0% |
| Active Temperature Compensation | Yes |
| Weight | Varies based on configuration |
| Battery Type | Rechargeable |
| Battery Life | 100 hours |
| Method of Cadence Measurement | Accelerometer |
| BCD | 144 5-bolt |
| Spindle Size | 24 mm or 30 mm |
| Q Factor | 145.5 mm |
| Warranty | 2 years |
