Flojet D3134B5011AR 3/8" NPT Duplex II Self-Priming Pump 8 LPM 12V - Totton

Model: D3134B5011AR

Duplex II

The Duplex II series of pumps incorporates the best technology and features developed by Flojet. Everything from the back-flow preventer, check valves, bearings and diaphragm assembly to the motor, has been designed to make this the most reliable diaphragm pump available. Higher efficiency of the pump is evident in the longer life of the motor pump unit. The diaphragm design combined with the new valves makes the pump capable of pulling higher dry vacuum. Duplex II is available in various performance ranges and voltages, and with a choice of elastomers, making it easily adaptable to a diverse range of applications.

Features
  • Intermittent duty
  • Duplex diaphragm design allows extended dry running
  • Self-primes up to 2.4m vertical lift

Specifications

BrandFlojet
RangeDuplex II Series
Diaphragm MaterialNitrile
Valve MaterialNitrile
Pump TypeDiaphragm
Porting3/8" NPT
Power12v
Max Temperature60 Degrees Celsius
Body MaterialPolypropylene
Max Flow Rate8 LPM
Pressure SwitchCuts in at 2.1bar (40 PSI) | Cuts out at 4.2bar (60 PSI)
Fuse Size10 amp
Dimensions204mm long, 101mm wide, 92mm high
connection 3/8 inch icon power 12v icon diaphragm material nitrile icon balls materials nitrile icon on demand duplex icon
