FOR BMW M550d 550i 650i 740i 750i FRONT REAR DRILLED BRAKE DISCS 374mm 345mm

Manufacturer Part Number Does Not Apply
Brand Kinetix
Placement on Vehicle Front, Rear, Left, Right
Reference OE/OEM Number 34 11 6 785 676,34116785676,34116785675,34106894383
Coated Yes
Note To Buyers Please Leave REG | VIN Number After Purchase
Features Drilled Surface
Country of Origin United Kingdom



BEFORE PURCHASING YOU MUST CONTACT US CONFRIMING YOUR VEHICLE DATA THIS CAN BE DONE BY USING THE TWO OPTIONS BELOW.


OPTION 1:

FOR UK REGISTERED VEHICLES ONLY WE NEED THE UK REG.


OPTION 2:

FOR NONE UK REGISTERED VEHICLES ONLY YOU MUST PROVIDE

THE FULL CHASSIS / VIN NUMBER. WITHOUT THIS INFORMATION WE WILL NOT SHIP ANYTHING THIS WILL ALSO AVOID ANY DISAPPOINTMENT OF RECEIVING INCORRECT PARTS.


PLEASE DO NOT BOOK YOUR SERVICE OR OPEN YOUR VEHICLE UNTIL THE PARTS ARE PHYSICALLY WITH YOU.

Front Axle Brakes Setup:
Brake Disc Type: High Carbon | Vented | Two Piece
Brake Disc Diameter: 374mm
Brake Disc Thickness: 36mm
Brake Disc Minimum Thickness: 34.4mm
Centering Diameter: 75mm
Height: 66.1mm

Rear Axle Brakes Setup:
Brake Disc Type: High Carbon | Vented | Two Piece
Brake Disc Diameter: 345mm
Brake Disc Thickness: 24mm
Brake Disc Minimum Thickness: 22.5mm
Centering Diameter: 75mm
Height: 69mm

Fits:

BMW 5 Series M 550d xDrive AWD -- F11 2012 - 2017
2993cc 280KW 381HP N57 D30 C

BMW 5 Series M 550d xDrive AWD -- F10 2012 - 2016
2993cc 280KW 381HP N57 D30 C

BMW 5 Series 550i RWD -- F11 2010 - 2013
4395cc 300KW 408HP N63 B44 A

BMW 5 Series 550i RWD -- F11 2013 - 2017
4395cc 330KW 449HP N63 B44 B

BMW 5 Series 550i xDrive AWD -- F07 2010 - 2012
4395cc 300KW 408HP N63 B44 A

BMW 5 Series 550i xDrive AWD -- F07 2012 - 2017
3982cc 300KW 408HP N63 B40 A

BMW 5 Series 550i xDrive AWD -- F07 2012 - 2017
4395cc 330KW 449HP N63 B44 B

BMW 5 Series 550i RWD -- F07 2009 - 2012
4395cc 298KW 405HP N63 B44 A

BMW 5 Series 550i RWD -- F07 2009 - 2012
4395cc 300KW 408HP N63 B44 A

BMW 5 Series 550i RWD -- F07 2012 - 2017
4395cc 330KW 449HP N63 B44 A;N63 B44 B

BMW 5 Series 550i xDrive AWD -- F10 2010 - 2013
4395cc 300KW 408HP N63 B44 A

BMW 5 Series 550i xDrive AWD -- F10 2012 2013
4395cc 298KW 405HP N63 B44 A

BMW 5 Series 550i xDrive AWD -- F10 2013 - 2016
4395cc 330KW 449HP N63 B44 B

BMW 5 Series 550i xDrive AWD -- F10 2013 - 2016
4395cc 332KW 452HP N63 B44 B

BMW 5 Series 550i RWD -- F10 2010 - 2013
4395cc 298KW 405HP N63 B44 A

BMW 5 Series 550i RWD -- F10 2010 - 2013
4395cc 300KW 408HP N63 B44 A

BMW 5 Series 550i RWD -- F10 2013 - 2016
4395cc 330KW 449HP N63 B44 B

BMW 5 Series 550i RWD -- F10 2013 - 2016
4395cc 332KW 452HP N63 B44 B

BMW 6 Series 650i xDrive AWD -- F12 2011 - 2012
4395cc 298KW 405HP N63 B44 A

BMW 6 Series 650i xDrive AWD -- F12 2011 - 2012
4395cc 300KW 407HP N63 B44 A

BMW 6 Series 650i xDrive AWD -- F12 2012 - 2018
4395cc 330KW 449HP N63 B44 A;N63 B44 B

BMW 6 Series 650i xDrive AWD -- F12 2012 - 2018
3982cc 300KW 408HP N63 B40 A

BMW 6 Series 650i xDrive AWD -- F12 2012 - 2018
4395cc 332KW 452HP N63 B44 B

BMW 6 Series 650i RWD -- F12 2010 - 2012
4395cc 300KW 408HP N63 B44 A

BMW 6 Series 650i RWD -- F12 2011 - 2012
4395cc 298KW 405HP N63 B44 A

BMW 6 Series 650i RWD -- F12 2012 - 2018
4395cc 330KW 449HP N63 B44 A;N63 B44 B

BMW 6 Series 650i RWD -- F12 2012 - 2018
4395cc 332KW 452HP N63 B44 B

BMW 6 Series 650i xDrive AWD -- F06 2012 - 2018
4395cc 330KW 449HP N63 B44 B

BMW 6 Series 650i xDrive AWD -- F06 2013 - 2018
3982cc 300KW 408HP N63 B40 A

BMW 6 Series 650i xDrive AWD -- F06 2013 - 2018
4395cc 332KW 452HP N63 B44 B

BMW 6 Series 650i xDrive AWD -- F13 2011 - 2015
4395cc 300KW 408HP N63 B44 A

BMW 6 Series 650i xDrive AWD -- F13 2012 - 2017
3982cc 300KW 408HP N63 B40 A

BMW 6 Series 650i xDrive AWD -- F13 2012 - 2017
4395cc 330KW 449HP N63 B44 B

BMW 6 Series 650i xDrive AWD -- F13 2012 - 2017
4395cc 332KW 452HP N63 B44 B

BMW 6 Series 650i RWD -- F06 2012 - 2018
4395cc 330KW 449HP N63 B44 B

BMW 6 Series 650i RWD -- F06 2013 - 2018
4395cc 332KW 452HP N63 B44 B

BMW 6 Series 650i RWD -- F13 2011 - 2012
4395cc 298KW 405HP N63 B44 A

BMW 6 Series 650i RWD -- F13 2011 - 2012
4395cc 300KW 408HP N63 B44 A

BMW 6 Series 650i RWD -- F13 2012 - 2017
4395cc 330KW 449HP N63 B44 B

BMW 6 Series 650i RWD -- F13 2012 - 2017
4395cc 332KW 452HP N63 B44 B

BMW 7 Series 750d xDrive AWD -- F01,F02,F03,F04 2012 - 2015
2993cc 280KW 381HP N57 D30 C

BMW 7 Series ActiveHybrid 7 RWD -- F01,F02,F03,F04 2010 - 2012
4395cc 330KW 449HP N63 B44 A

BMW 7 Series ActiveHybrid 7 RWD -- F01,F02,F03,F04 2010 - 2012
4395cc 342KW 465HP N63 B44 A

BMW 7 Series ActiveHybrid 7 RWD -- F01,F02,F03,F04 2012 - 2015
2979cc 235KW 320HP N55 B30 A

BMW 7 Series ActiveHybrid 7 RWD -- F01,F02,F03,F04 2012 - 2015
2979cc 260KW 354HP N55 B30 A

BMW 7 Series 750 Li xDrive AWD -- F01,F02,F03,F04 2008 - 2015
4395cc 298KW 405HP N63 B44 A

BMW 7 Series 750 Li xDrive AWD -- F01,F02,F03,F04 2013 - 2015
3982cc 300KW 408HP --

BMW 7 Series 750i, Li xDrive AWD -- F01,F02,F03,F04 2009 - 2012
4395cc 300KW 408HP N63 B44 A

BMW 7 Series 750i, Li xDrive AWD -- F01,F02,F03,F04 2012 - 2015
4395cc 330KW 449HP N63 B44 B

BMW 7 Series 750 Li RWD -- F01,F02,F03,F04 2008 - 2015
4395cc 298KW 405HP N63 B44 B

BMW 7 Series 750i, Li RWD -- F01,F02,F03,F04 2008 - 2012
4395cc 300KW 408HP N63 B44 A

BMW 7 Series 750i, Li RWD -- F01,F02,F03,F04 2012 - 2015
4395cc 330KW 449HP N63 B44 B

BMW 7 Series 750i RWD -- F01,F02,F03,F04 2012 - 2015
4395cc 331KW 450HP N63 B44 B

BMW 7 Series 760i, Li RWD -- F01,F02,F03,F04 2009 - 2015
5972cc 400KW 544HP N74 B60 A


Kinetix high performance brake discs are a direct replacement for your OEM brakes without any modifications. Designed to significantly improve your vehicle's stopping power giving you the confidence to drive harder and push further than ever before.

The coss drilled holes produce a scraping effect that cleans the surface of the pad from hazardous material deposits, thus preventing that even the slightest amount of ferrous material – that come from the brake disc wear- can sediment on the friction material of the brake pad.

The presence of the cross drilled holes leads to greater air circulation, resulting in improved heat dissipation capability and its increased performance.

Features:

1: Improved Braking Performance - These rotors are designed to enhance your car's stopping power, providing better overall braking performance. Whether you're hitting the brakes hard or cruising around town, these rotors will give you that extra confidence and control.

2: Heat Dissipation - With their cross drilled design, these rotors offer excellent heat dissipation. This helps to prevent brake fade, ensuring consistent and reliable braking even during intense driving situations.

3: Silver anti corrosion coating on non-friction areas reduces corrosion & ensure your disc rotors last longer.

4: Cleaner Braking Surface - The drilled holes in these rotors allow brake dust and debris to escape, keeping the braking surface cleaner. This means better contact between the brake pads and rotors, resulting in more effective braking.

5: Visually pleasing on the car. Get that sporty look behind your wheels!

6: The cross drilled holes serve to prevent water film that may form on the braking surface. Even when driving on slick roads the brake system responds effectively already at the first braking.

High Carbon:

Improved driving comfort –
High carbon content in cast iron ensures softer disc operation.

Excellent product design –
Kinetix brake discs are made of an improved cast iron alloy. Their manufacturing process is strictly controlled and the content of specific components is closely monitored.

Improved thermal conductivity –
Kinetix brake discs made of high carbon cast iron feature improved thermal conductivity and decreased heating of the brake disc contact area.
