Plate Heat Exchanger - Ba-27 1 1/4 inch
Producer: Nordic Tec Europe
We ship our goods from the EU. Since Brexit (1.01.21) import fees may occur.
Please note that those charges if occur - are always on Buyer's side.
The delvieries in the EU countries generate no additional fees or charges.
- Material - 316L stainless steel with anticorosion system, brazed with copper (99,9% Cu)
- Working pressure (max.) - 30 bar - Testing pressure - 45-60 bar
- Temperature - from -185 to 230 °C
- Connectors - 4x 1 1/4" (all the connections are 5/4" - DN32 - external thread)
- Typical aplications:
- heating & cooling
- cooperating with boilers, solar pannels, infloor heating, food industry, beer industry and many others - Flow - 12 m3/h
- Certified - PED 97/23/EC
- You can also optionally buy the PHE with WALL SUPPORT SET (which contains also Fittings)
- Wall-mounting set DN32 (OPTIONALLY)
Dimensions:
- Length (A) - 286 mm
Width (B) - 116 mm
Wheel base (C) - 234 mm
Wheel base (D) - 63 mm
Height (F) - (2.4mm x Number of Plates) + 7mm -
NORDIC TEC Ba-27 1 1/4" Series
PHE Model
Ba-27-20 125kW
Ba-27-40 230kW
Ba-27-60 330kW
Ba-27-70 390kW
Ba-27-80 450kW
Ba-27-90 500kW
-
Plates Q-ty
20
40
60
70
80
90
-
Heat Transfer Area
0.54 m²
1.08 m²
1.62 m²
1.89 m²
2.16 m²
2.43 m²
-
Depth (F)
55mm
103mm
103mm
175mm
201mm
230mm
-
The rated capacity (nominal power) of heat exchangers is the capacity calculated with high parameters (i.e., high temperatures and flow rates). It is not related to the capacity in kW of the heating device (fireplace, heat pump, or boiler) for which the heat exchanger is used. Selecting a heat exchanger is not always easy and should be done by a professional or someone who has the experience.
