| Parameter |
| DC volt | 12V |
| Voltage Range | 10-15VDC |
| NO Load Current Draw | <1.5A |
| Efficiency | >85% |
| DC Connector Cables | Cables |
| AC Voltage | 110~120VAC |
| Continuous Power | 5000W |
| Surge Power | 10000W |
| Waveform | Pure Sine Wave |
| Frequency | 60HZ |
| AC Regulation | 3% |
| Low Voltage Alarm | 10DC±0.5V |
| Low Voltage Shut Down | 9.5DC±0.5V |
| Over Load | Shut Off Output |
| Over Voltage Shut Down | 15.5V dc |
| Over Thermal | Shut Off Output Automatically |
| Fuses | Short Circuit |
| Working Temperature | Between -10centi and +50centi |
| Working Humidity | 20%~90%RH non-condensing |
| Storage Temperature | Between -30centi and +70centi |
| Start | Soft Start |
| Cooling Ways | Cooling Fan |
| Total Harmonic Distortion THD | <5% |
| Machine Size(mm) | 467*246*94 |
| Packing Size(mm) | 630*330*210 |
| Net Weight(kgs) | 7.9 |
| Gross Weight(kgs) | 9.8 |
