RMStator Ignition Coil Kit For 2012-2013 Can-Am Outlander Max 800R 4x4 XT

SPECIFICATIONS
Product SKU: RMS900-106728 M-055
Brand: RMStator
Condition: New

Stock image. Actual product may vary.

For additional product details or technical questions, please contact us.
Monday-Friday 9AM to 6PM Eastern Time.

Free Ground Shipping

Easy Returns

Secure Payments

Great Customer Service

Product Details

RMStator Ignition Coil Kit For 2012-2013 Can-Am Outlander Max 800R 4x4 XT



RMStator Ignition Coil Kit For 2012-2013 Can-Am Outlander Max 800R 4x4 XT


Brand New Kit External Ignition Coil + Spark Plug Caps

  • All products shipped are tested.
  • All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.

Brand new aftermarket External Ignition Coil

  • Direct replacement to your original unit
  • Plug-and-play unit, direct fit, and easy to install.

Brand new aftermarket Spark Plug Caps

  • Direct replacement to your original unit
  • The Quality exceeds the OEM equipment
  • 2 Spark plug caps included

If your old parts are defective, we offer replacement parts of high quality at a fraction of the cost of genuine parts.

Some models combine the spark plug caps and coils to reduce the number of parts used to improve efficiency. However, when your plug caps wear out, it is more expensive to replace them. If you are experiencing ignition problems, this could mean the coil plug cap needs replacing. The replacing is simple to do and help with the efficient running of your engine.



Technical Data

External ignition coil Dimensions:
Width: 72 mm
Length: 100 mm
Height: 45 mm

Resistance:
Primary Resistance (between terminals 1&2 and 2&3): 0.9 ohms +/-20%
PTO Spark Plug Wire: 7.0k ohms +/- 5%
MAG Spark Plug Wire: 7.4k ohms +/- 5%

Spark Plug Caps Dimension:
Wire length: 325 mm & 575 mm
Diameter: 6.6 mm
Resistance:
Primary = 0.9 ohms

RMSTATOR are committing to innovate in finding clever ways to design more efficient parts that produce better results than any other part on the market.

We do not just sell electrical parts for powersports, we solve problems. RMSTATOR take pride in designing & manufacturing more efficient parts, providing all the information necessary for an easy and reliable installation, and supporting the customer before, during, and after the sale.

THE POWER IN POWERSPORTS

Brand: RMStator
Part Number: RMS900-106728

Fitment:

  • 2000-2005 Bombardier Traxter 500 4x4 Automatic
  • 2001-2005 Bombardier Traxter 500 XL Carb F/C
  • 2003-2005 Bombardier Traxter Max 500 4x4 Automatic
  • 2011-2015 Can-Am Commander 1000 4X4
  • 2011 Can-Am Commander 800 4X4
  • 2012-2015 Can-Am Commander 800R 4X4
  • 2015-2017 Can-Am Commander Max 1000 4X4
  • 2016-2017 Can-Am Commander Max 800R 4x4 DPS
  • 2016-2017 Can-Am Defender HD10 4X4
  • 2016-2017 Can-Am Defender HD8 4X4
  • 2017 Can-Am Defender Max HD10 4x4 DPS
  • 2013-2015 Can-Am Outlander 1000 4x4 DPS
  • 2012 Can-Am Outlander 1000 4x4 EFI
  • 2013-2015 Can-Am Outlander 1000 4x4 XMR
  • 2012-2017 Can-Am Outlander 1000 4x4 XT
  • 2013-2015 Can-Am Outlander 1000 4x4 XTP
  • 2007-2014 Can-Am Outlander 500 4x2
  • 2013-2015 Can-Am Outlander 500 4x4 DPS
  • 2007-2009 Can-Am Outlander 500 4x4 XT
  • 2012-2015 Can-Am Outlander 500 4x4 XT
  • 2016-2017 Can-Am Outlander 570 4X4
  • 2013-2016 Can-Am Outlander 650 4x4 DPS
  • 2006-2017 Can-Am Outlander 650 4x4 EFI
  • 2013-2015 Can-Am Outlander 650 4x4 XMR
  • 2006-2009 Can-Am Outlander 650 4x4 XT
  • 2012-2017 Can-Am Outlander 650 4x4 XT
  • 2011-2015 Can-Am Outlander 800R 4X4
  • 2013-2015 Can-Am Outlander 800R 4x4 DPS
  • 2011-2012 Can-Am Outlander 800R 4x4 XMR
  • 2015 Can-Am Outlander 800R 4x4 XMR
  • 2012-2015 Can-Am Outlander 800R 4x4 XT
  • 2013-2015 Can-Am Outlander 800R 4x4 XTP
  • 2011 Can-Am Outlander 800R 4x4 XXC EFI
  • 2013-2015 Can-Am Outlander Max 1000 4x4 DPS
  • 2016 Can-Am Outlander Max 1000R 4x4 XT DPS
  • 2007-2014 Can-Am Outlander Max 500 4X4
  • 2013-2015 Can-Am Outlander Max 500 4x4 DPS
  • 2008 Can-Am Outlander Max 500 4x4 XT
  • 2012-2015 Can-Am Outlander Max 500 4x4 XT
  • 2016-2017 Can-Am Outlander Max 570 4X4
  • 2006-2013 Can-Am Outlander Max 650 4X4
  • 2015 Can-Am Outlander Max 650 4X4
  • 2013 Can-Am Outlander Max 650 4x4 DPS
  • 2015-2016 Can-Am Outlander Max 650 4x4 DPS
  • 2008-2009 Can-Am Outlander Max 650 4x4 XT
  • 2012-2013 Can-Am Outlander Max 650 4x4 XT
  • 2015-2016 Can-Am Outlander Max 650 4x4 XT
  • 2012 Can-Am Outlander Max 650 4x4 XTP EFI
  • 2007-2008 Can-Am Outlander Max 800 4x4 HO EFI
  • 2013 Can-Am Outlander Max 800R 4x4 DPS
  • 2015 Can-Am Outlander Max 800R 4x4 DPS
  • 2009-2012 Can-Am Outlander Max 800R 4x4 EFI
  • 2014 Can-Am Outlander Max 800R 4x4 EFI
  • 2012 Can-Am Outlander Max 800R 4x4 LTD EFI
  • 2012-2013 Can-Am Outlander Max 800R 4x4 XT
  • 2015 Can-Am Outlander Max 800R 4x4 XT
  • 2012-2013 Can-Am Outlander Max 800R 4x4 XTP
  • 2015 Can-Am Outlander Max 800R 4x4 XTP
  • 2012-2015 Can-Am Renegade 1000 4X4
  • 2012-2014 Can-Am Renegade 1000 4x4 XXC
  • 2008-2015 Can-Am Renegade 500 4X4
  • 2016-2017 Can-Am Renegade 570 4X4
  • 2007-2008 Can-Am Renegade 800 4x4 HO EFI
  • 2009-2015 Can-Am Renegade 800R 4X4
  • 2010-2014 Can-Am Renegade 800R 4x4 XXC
  • 2007-2008 Ski-doo Expedition V800 Sport EFI L/C
  • 2007-2009 Ski-doo Expedition V800 TUV V 4-TEC EFI L/C
  • 2007 Ski-doo Legend V800 Trail EFI L/C
  • 2007-2012 Ski-doo Skandic V800 SWT EFI L/C
  • 2007 Ski-doo Skandic V800 Tundra EFI L/C
  • 2008-2009 Ski-doo Skandic V800 Tundra LT 4-TEC EFI L/C

Note: Image is for reference only, actual product may vary slightly.

OEM Numbers:
106728-R00
