FEATURES:

【315 & 433MHz in 1 Sensor】

This tire pressure monitoring sensor (for TPMS) has been manufactured to combine both 315 MHz and 433 MHz applications in one sensor to greatly simplify users’ inventory management and lower the investment as well as sales loss. And it is built to perform like OE sensors in terms of signal, durability and functionality.

【98% Vehicle Coverage】

An easy to use and cost effective necessity for any shop performing TPMS repairs, the Autel 1-SKU sensor has the long ability to cover over 98% of all OE sensors on the market, to support up 90% of North American, European and Asian brands. On the shop level, needing only 1-Sensor to service nearly every TPMS equipped vehicle means lower repair cost and higher install efficiency.

【Patented Press Release】

With both rubber and metal accessory valve stems available, our accessory valve kits minimize service time and provide a quick assembly for installation. The patented press release valve design allows interchangeable rubber and metal valves to be easily replaced in the same sensor head by hand, with no valve fitting tool required. Simply click in and press out. Installing TPMS sensors has never been so easy.

【Maximum Signal Strength】

The extraordinary sensor signal strength allows Autel 1-Sensor to be easily pro_grammed wirelessly even when the sensors have already been mounted to the wheel. Autel MX-Sensor is 100% clone-able with an Autel latest wireless TPMS pro_gramming tool. No relearn is required when the MX-Sensor is cloned with the original sensor ID and put in the same position.

【Superior Battery Reliability】

With the highest quality materials and advanced TPMS technology, Autel1-Sensor provides superior battery life and reliability, to match OE sensor battery performance. The 1-Sensor body weighs only 12g, making it significantly lighter than most sensors in the market, which ensures better sensor stability and performance.

【Strict Quality Control】

Autel guarantees MX-Sensor are free from manufacturing defects for a period of 24 months or 24,000 miles, whichever option comes first. Each Autel MX-Sensor has a series number for assuring quality control. The series number is imprinted on the sensor or can be read with Autel TPMS tools. With the series number, Autel can track the sensor quality from our factory manufacturing to ensure only the highest quality parts are installed.





WARRANTY:

Autel guarantees that the sensor is free from material and manufacturing defects for a period of 2 years or within 24,000 running miles, whichever comes first.100% ID clone-able and no relearn required. Tested and certified to meet SAE standards.

TIPS:

Welcome to get technical support via email/Q&A, or hotline on our official site, if you are unsure whether the sensor is suitable for your vehicle, or any questions.







SPECIFICATION:

Battery Life: ≥5 years

Operating Temperature: -40°C – 125°C

Storage Temperature: -40°C t – 125°C

Operating Humidity: ≤90%

Operating Frequency: 315 MHz~433MHz

Max. Pressure range: 800 kPa

Temperature Reading Range: -40°C – 125°C

Temperature Reading Accuracy: ±5°C

G Sensor Reading Accuracy: ±15%

Transmission Power: 5-8dBm

Battery: 3.0 V

Dimensions: Approx. 42.4*24.1*16.0 mm

Weight of Sensor without Valve: 11 g

PACKAGE LIST:

1*Main Unit

1*User Manual
