Precision Industry Ddts380 400Kg/cm Large Steering Gear 24V Power Supply Precision Steering Gear High Torque Industrial Area
feature:
1. Suitable for servo controllers and model aircraft remote controls
2. Alloy gear high torque motor
3. Ultra-light aluminum alloy gearbox
4. Easy to install, durable, reliable, stable and practical
application:
Large robot, mechanical arm power joint
Industrial Robot Automation
Precise control of valve angle
Large camera pan/tilt
Large-scale remote control car model, remote control boat model
Technical Parameters:
- Rated voltage: DC 24V (12V-24V can work, 12V torque and speed are halved)
- No-load current: <500MA (load current 5-10A, it is recommended to use 10A or above switching power supply or battery, the larger the power supply current output capacity, the better)
- Limit angle: 1200-1700US: about 90 degrees; 500-2500US: about 288 degrees (the pulse width determines the angle, if you need other angles, please increase or decrease the pulse width yourself, the maximum is about 288 degrees)
- Control mode: 1.0-2.0 millisecond pulse: suitable for aircraft model remote control receiving control; 0.5-2.5 millisecond pulse: suitable for multi-channel steering gear controller control (pulse frequency: 50-333HZ)
- Material: * Gears and Shafts: Alloy Steel, Hardened Steel, Aluminum Alloy; * Housing: Aluminum Alloy
- Servo weight: about 880g
- Speed: 0.5S/60° (equivalent to 20RPM)
- Mechanical life: >300,000 times (370 hours)/(30KG/CM)
- Torque limit: 400KG/CM (broken gear load, it is not recommended to work under this torque)
- Starting torque: 380KG/CM (short-time work)
- Conventional torque: 140KG/CM (can work for a long time)
