Video:
BS-4525A box heat shrinking tunnel for plastic film
Video will open in a new window
Using the eBay App? Paste link into a browser window:
Description:
BS-A series shrink tunnel adopts hot-wind & down-cyclone structure, intelligence temperature control and AC variable speed regulation. There are two optional conveyors, including Teflon belt type and roller type.
Features:
1. Both the height of tunnel and shutters on two sides are adjustable.
2. Shrink wrapping machine BS-3020A & BS-4525A adopts single hot wind tunnel,
3. Shrink wrapping machine BS-4535LA & BS-6535LA are designed with lengthened double hot wind tunnel for higher and better shrinking effect.
Application:
BS-A series shrink tunnel are applied to heat shrinkable film such as PVC, POF, PP etc.
Product Paramenters:
|
|
BS-3020A |
BS-4525A |
BS-4535LA |
BS-6535LA |
|
Voltage(V/Hz) |
220/50(single phase) 380/50(3 phase) 220/60(3 phase) |
380/50(3 phase) 220/60(3 phase) |
||
|
Power(kw) |
5.1 |
7.5 |
10 |
13 |
|
Loading(kg) |
10 |
30 |
||
|
Speed(m/min) |
0-10 |
|||
|
Tunnel Size(L×W×H)(mm) |
900×300×(50~200) |
900×450×(50~250) |
1200×450×(50~350) |
1200×650×(50~350) |
|
External Dimensions(L×W×H)(mm) |
1200×500×1050 |
1200×650×1100 |
1600×650×1200 |
1600×850×1200 |
|
Net Weight(kg) |
60 |
90 |
120 |
150 |
Packaging Details:
|
Model
|
BS-4525A
|
|
Pcs/CTN (pc)
|
1
|
|
Package Type
|
W/C
|
|
Gr. Wt. (kg)
|
112
|
|
Net. Wt. (kg)
|
100
|
|
Dimensions(cm)
|
124*74*57
|
|
Volume each set (cbm)
|
0.523
|
