Surecom SF401 Plus 27Mhz-3000Mhz Radio Portable Frequency Counter Meter with CTCCSS DCS Decoder for Walkie Talkie

Introduction:

1. The frequency meter capable of measuring the parameters of the frequency of the continuous carrier signal walkie-talkies , with signal strength indicator. it is the tool of choice for maintenance personnel,test frequency and signal strength of wireless enthusiasts.

2. This portable frequency counter is designed for counting continuous wave signal comes from Two-way Radio.

3. There are easy ranges for you to choose. The ranges cover most of the frequency of the two way radios you want to measure.

4. Its four-button control is easy to use and its small size allows you to carry it anywhere you like.
Work by TCXO(Temperature Compensate X\'tal (crystal) Oscillator) ,In the range of -45 C ~ 65 C can reach 2 ~ 4ppm accuracy

Feature & Specification:
* Frequency range: 27Mhz-3000Mhz
* CTCSS/DCS Decoder
* LCD Dim level setting
* Frequency digital 0000.000 or 0000.0000
* Work by TCXO(Temperature Compensate X\'tal (crystal) Oscillator) 2-2.5ppm
* Rresponse time: 0.2s.
* Color Display
* Build-in Li-ion battery
* Net Weight: 113g
* 4 buttons control
* Auto power off 1-9minutes
* Charging battery LED indicator
* New Function Frequency Counter for DIGITAL Radio

Specifications:
Brand Name:	SURECOM HK
TFT LCD:	320 x 240 pixels
Frequency Range:	27Mhz -3Ghz
Li-ion Battery build-in :	3.7V 600mah
current consumption:	10ma
TCXO crystal Oscillator	+- 2.5ppm
Change in:	Micro usb +5V
impedance input:	50 Ohm (BNC)
Weight:	113g
Dimensions size :	70 x 30 x 90mm

Frequency Counter

CTCSS

CTCSS (Hz)
50.0	97.4	151.4	192.8
55.0	100.0	156.7	196.6
67.0	103.5	159.8	199.5
69.3	107.2	162.2	203.5
71.9	110.9	165.5	206.5
74.4	114.8	167.9	210.7
77.0	118.8	171.3	218.1
79.7	123.0	173.8	225.7
82.5	127.3	177.3	229.1
85.4	131.8	179.9	233.6
88.5	136.5	183.5	241.8
91.5	141.3	186.2	250.3
94.8	146.2	189.9	254.1

CDCSS

Standard	sf401 check	Standard	sf401 check	Standard	sf401 check	Standard	sf401 check
Standard	sf401 check	Standard	sf401 check	Standard	sf401 check	Standard	sf401 check
23	23	143	143		266	465	465
25	25		145	271	271	466	466
26	26	152	152		274	503	503
31	31	155	155	306	306	506	506
32	32	156	156	311	311	516	516
	36	162	162	315	315	532	532
43	43	165	165		325	546	546
47	47	172	172	331	331	565	565
51	51	174	174		332	606	606
	53	205	205	343	343	612	612
54	54		212	346	346	624	624
65	65	223	223	351	351	627	627
71	71		225		356	631	631
72	72	226	226	364	364	632	632
73	73	243	243	365	365	654	654
74	74	244	244	371	371	662	662
114	114	245	245	411	411	664	664
115	115		246	412	412	703	703
116	116	251	251	413	413	712	712
	122		252	423	423	723	723
125	125		255	431	431	731	731
131	131	261	261	432	432	732	732
132	132	263	263	445	445	734	734
134	134	265	265	464	464	743	743
						754	754

Package Contents ：

1* SF401 plus Frequency Counter

1* UHF Antenna

1* User Manual

1* USB charger cable

1* USB AC adapter 100-240V
