Real-time sampling rate: 1Msps
Accuracy: 12Bit
Sample buffer depth: 1024 bytes
Analog bandwidth: 0 - 200KHz
Vertical sensitivity: 10mV/Div – 5V/Div (inward by 1-2-5)
Vertical displacement adjustable with indication
Input impedance: 1MΩ
High input voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe)
Coupling methods include DC/AC/GND
Horizontal time base range: 10μs/Div – 50s/Div (inward by 1-2-5)
Automatic, regular and single trigger mode for easy capture of instantaneous waveforms
Trigger with rising or falling edges
Trigger level position adjustable with indication
Observe the waveform before the trigger (negative delay)
The waveform display can be frozen at any time (HOLD function)
Self-contained 1KHz / 3.3V square wave test signal source
