6AN 8AN 10AN Swivel Hose End Fitting 0 Degree/45 Degree/90 Degree/180 Degree for Braided CPE Fuel Line Aluminum
Specification:
Size:6AN,8AN,10AN
Angle: 0 Degree,45 Degree,90 Degree,180 Degree
Material: Aluminum
Color: Red and Blue
Package Includes: 1 piece
Size:6AN,8AN,10AN
Angle: 0 Degree,45 Degree,90 Degree,180 Degree
Material: Aluminum
Color: Red and Blue
Package Includes: 1 piece
Please attention that the fitting only be worked with Braided CPE fuel line. It can not be installed on PTFE Hose.
Thread Size of 10AN hose fitting is 7/8-14UNF and the braided CPE fuel line which works with should be 5/8".
Thread Size of 8AN hose fitting is 3/4-16UNF and the braided CPE fuel line which works with should be 1/2".
Thread Size of 6AN hose fitting is 9/16-18UNF and the braided CPE fuel line which works with should be 3/8".
Swivel design for easy assembly, the adjustable AN wrench is highly recommended.
Package Inclued: 1pc swivel hose end
