Specification:

1.High-contrast IPS dot screen.

2. UART-BUS Communication Protocol.

3. Customized Start-Up Logo,dynamic displaying.

4. Set up Password of Turning on.

5. Speed display: RT SPEED MAX SPEED AVG SPEED.

6. KM/ Mile: Setting up adjustable according to customers' habits.

7. Mileage: ODO, Trip, Time, Range.

8. Clock.

9. Power indicator.

10. Error code.

11. USB charging port: 5V/500mA.

12. Software Update.

13. Friendly HMI.

14. 36V/48V compatible.

15.IP-Code IP65

16.Certifications CE/EN15194 Rohs

17.Handlebar for Holding:Ø 22.2/25.4/31.8 mm

1.Bafang LCD display

2.Display holder

This display Works with the BBS01, BBS02 & BBSHD mid drive motor, and all electric bikes with bafang motor

This LCD Display can fit Bafang 8fun Mid Drive BBS01/02/03 BBSHD

Displays volts for highly accurate battery gauge giving you a good idea when your battery will die

Automatic back light, Black or white background can be toggled

Odometer, trip time, clock and total mileage Variable throttle option for limiting throttle in different power levels

Do not plug in or unplug this display when the power to the unit is on.

Avoid collisions.

Protect the display’s membrane to provide water resistant performance.

Do not attempt to reset parameters if the display is not working.

Install the display and button control on the handlebar and adjust its location. Plug it into the controller with power off.

1.We have oversea warehouse in United States ,Russia ,Germany ,Spain ,Poland ,Canada ,Australia and Japan .You could choose the delivery location when you place your new order or we will according to your location to choose the fast shipping warehouse for you .Enjoy the fastest and most convenient local logistics and after -sale service

2.We provide the product 1 year warranty .
