T3 Turbo Manifold + Turbocharger Kit for BMW E36 320i 323i 325i 328i 90-99 420HP

Images


Features

- OEM specs coincidence to ensure the perfect fitment to the related parts

- Material qualification for durable and reliable use

- Multi-Discipline tests, like balance, housing durability, wheel load limits, sealing, etc. are carried to enhance the quality of every unit

- Accuracy producing on all procedures to reduce possible metallic contacts under different condition

- Large range of turbochargers for easily locate the turbo with the target horse power and size you need from us

- Quality fully guaranteed and professional installation highly recommended


All modifications must be installed by licensed mechanics and in compliance with your local modification regulations

​​​​​​​



Please confirm that there is enough space in your car to install this turbo before purchasing.



For BMW    E36    320i    M50 B20    1990-1992
For BMW    E36    320i    M50TU B20    1992-1994
For BMW    E36    320i    M52 B20    1994-1999
For BMW    E36    323i    M52 B25    1994-1999
For BMW    E36    323ti    M52 B25    1997-2000
For BMW    E36    325i    M50 B25    1989-1992
For BMW    E36    325i    M50TU B25    1992-1995
For BMW    E36    328i    M52B28    1994-1999
For BMW    E34    520i    M50B20    1990-1992
For BMW    E34    520i    M50TU B20    1992-1995
For BMW    E34    525i    M50B25    1990-1992
For BMW    E34    525i    M50TU B25    1992-1996
For BMW    E39    520i    M52B20    1996-1999
For BMW    E39    520i    M52TUB20    1998-2000
For BMW    E39    523i    M52B25    1995-1998
For BMW    E39    523i    M52TUB25    1998-2000
For BMW    E39    528i    M52B28    1995-1998
For BMW    E39    528i    M52TUB28    1998-2000
For BMW    E46    320i/320Ci    M52TUB20    1998-2000
For BMW    E46    323i/323Ci    M52TUB25    1998-2000
For BMW    E46    328i/328Ci    M52TUB28    1998-2000
For BMW    Z3 Z3    2.0 i    M52TUB20    1998-2000
For BMW    Z3 Z3    2.8 i    M52B28    1997-1999
For BMW    E38    728i/728iL    M52TUB28    1998-2001
For BMW    E38    728i/728iL    M52B28    1996-1998



Application

Compatible for 1.5L to 2.5L any 4/6 cylinder engine
Horse Power: Capable of Boosting Horse Power up to 420HP
Cooling Type: Oil Cooled
Oil Inlet: M12*1.25 & 2*M8*1.25
Oil Outlet: 2*M8*1.25
Wastegate：With Wastegate
Thrust Bearings: 270 Degrees
Turbo Type: Individual
Condition:  Brand New
Accessories: You will get exactly as shown as picture above
Package Size:30x 28x 24 cm
Package Weight: 9180g



Specification
Exhaust Inlet (Turbo Manifold) Flange: T3 4 bolt Flange Patterns
Exhaust Outlet  Flange: V-Band Flange  (ID/OD: 2.5"/3.1")
Turbine Trim: 74.2
Turbine Inducer Diameter:  64.8 mm
Turbine Exducer Diameter: 55.8mm
Turbine A/R: 0.63
Turbine exhaust  outlet : 79mm
Turbine exhaust inlet：44.7mm（length）/85.8mm（width）


Compressor outlet：78 mm
Compressor inlet：51.5 mm
Compressor Trim: 48.1
Compressor Inducer Diameter: 52.7mm
Compressor Exducer Diameter: 76 mm
Compressor A/R: 0.5
Bearing: Journal Bearing
Warranty: 2 Year




Exhaust Manifolds

Flange size :T3 Flange, fit T3 and T3/T4 turbo
External Wastegate Flange : 35mm/38mm
Flange Connecting dimensions : 86mm x 45mm
Condition : 100% Brand New, Never Used or Installed
Material: Cast Iron Turbo Manifold
Note: Bottom Mount Exhaust Manifold



Feature

*Product Material
1. Turbine housing ：Ductile iron QT450-10 - temperature resistant up to 700℃
2. Steel turbine wheel：K418 alloy -  high  oxidation stability and resistance  up  to 900℃
3. Compressor housing：ZL104 aluminum with lightweight
4. Compressor wheel/blades：Cast aluminium blades – superior air tightness & corrosion resistance

*Product Features
1. Cost-effective turbo increase 20-40% power for your car
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance
4. Built for Thermal Stability and strength

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS  VSR3
2. G3-min-Flow VNT Turbo testing
3.  Advanced Actuator Tester/Programmer



Notice

* Replace, repair or reconnect air cleaner element per manufacturer's manual to avoid compressor wheel damage.
* Make sure the oil drain line is lower than the turbo itself.
* Ensure exhaust outlet are well sealed by welding
* The degree of modification of the universal turbo depends on your individual vehicle.Professional installation is highly recommended.
* This Turbo is not vehicle specific. Please check the specifications and verify compatibility prior to placing your order.
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
