| Capacity | 512GB |
| Form factor | M.2 2280 |
| Interface | PCIe 3.0 |
| Performance | Sequential Read/Write:512GB: up to 3500MB/s read, 2400MB/s write speedsRandom Read/Write512GB: up to 200K IOPs read, 256K IOPs write speeds |
| Total bytes written | 512GB: 250TB |
| Operating temperature | 0°C to 70°C (32°F to 158°F) |
| Storage temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimension (L x W x H) | 80 mm x 22 mm x 2.25 mm / 3.15” x 0.87” x 0.09” |
| Shock resistant | 1500 G, duration 0.5ms, Half Sine Wave |
| Vibration resistant | 10~2000Hz, 1.5mm, 20 G, 1 Oct/min, 30min/axis(X,Y,Z) |
| DWPD | 512GB: 0.44 |
| NAND flash | 3D TLC |
| MTBF | 1,500,000 Hours |
| Warranty | 5 year limited warranty |
